English
13
Input power source Single phase: AC 120 V 60 Hz
Charging time Approx. 50 min. (At a temperature of 68°F (20°C))
Charger
Charging voltage .......................... DC 24 V
Charging current ........................... DC 2.5 A
Weight 1.3 lbs. (0.6 kg)
2. Battery Charger (UC24YFB)
* Do not use the “SAVE” mode when boring holes with the wood drill. There is a likelihood
that the motor will burn out.
SPECIFICATIONS
1. Cordless Rotary Hammer (DH24DV)
Motor DC motor
No-load speed SAVE/POWER 0–500/min. / 0–1000/min.
Full-load impact rate SAVE/POWER 0–2200/min. / 0–4500/min.
Concrete 15/16
″ (24 mm)
Capacity Drilling Steel 1/2
″ (13 mm)
Wood 1–3/16
″ (30 mm) *
Battery (EB2420)
Nickel cadmium battery
Voltage ........ DC 24 V
Weight 8.9 lbs. (4.0 kg)
