D. Elevated Hearth Systems
Use the table below to identify the hearth system that will be used. The table will also help identify effects on the various
dimensions. Some hearth systems will elevate the appliance off the fl oor at a given dimension. The dimension noted in the
table below, in the Elevated Appliance Dimension Column, will also have to be added to the following: Extension Wall Hole
referenced in Figure 8.2 (Exterior Wall Hole) and Rough Opening Height (header height) referenced in Figure 5.2. Note:
Finished fl oor thickness should also be considered when determining installation dimensions.
MODEL DESCRIPTION PART #
ELEVATED APPLIANCE DIMENSION
See Note 1
ESC-42ST
Avalon Cast Mantel AFANTC5244 1/2 in.
Biltmore Cast Mantel AFBETC5244 1/2 in.
Hearst Cast Mantel AFHTTC5244 1/2 in.
Note 1. Add dimensions to Exterior Wall Hole (Figure 8.2) and Rough Opening Height (Figure 5.2).
The above listed Hearth and Home Technologies manufactured hearth systems have been tested and certifi ed for use with
the ESC-42ST fi replace. The dimensions of these Hearth and Home Technologies manufactured hearth systems may
differ slightly from the mantel specifi cations listed in Section 5.D and Section 13.A. The above listed Hearth and Home
Technologies manufactured hearth systems are not required to meet the mantel specifi cations listed in Section 5.D and
Section 13.A.
