D. Service Parts (continued)
Service Parts
09/08
Part numbers on following page.
Service Parts List
CR36D
36 in. Corner Right W
oodburning Fireplaces
2 - Damper Kit
6
1
5 4
10
3
8 9
7
Beginning Manufacturing Date:
Aug. 1997
Ending Manufacturing Date:
Active
Service Parts
09/08
Service Parts List
CR36D
36 in. Corner Right W
oodburning Fireplaces
Beginning Manufacturing Date:
Aug. 1997
Ending Manufacturing Date:
Active
IMPOR
TANT
: THIS IS DA
TED INFORMA
TION. When requesting service or replacement
parts for your appliance please provide model number and serial number
. All parts listed
in this manual may be ordered from an authorized dealer
.
Stocked at Depot
ITEM
D
ESCRIPTION
COMMENTS
P
A
RT NUMBER
1
S
tarter Section
Assembly
22069B
Y
2
D
amper Repair Kit
4010-001
3
S
moke Shield
17903
4
Side Refractory
Pre 8/91
11
821A
Post 8/91
16757
5
F
ront Ashlip
12592A
6
Lower Front Face
Pre Serial #AK583441
23912
7G
ra
te
GR3R
Y
8
S
ide Ashlip
12593A
9
Refractory - Back
Pre 8/91
12589A
Post 8/91
16814B
10
Side Smoke Shield
17901
Firescreen
Assembly
Qty
. 3 req.
12624
Y
Screen Handle
4021-150
Firescreen Rod
Qty
. 3 req.
12332A
Y
Grate Clips
Qty
. 2 req.
28062
Nailing Flanges
Qty
. 4 req.
31
190
Refractory - Hearth
12591A
Refractory Retainer
Qty
. 2 req.
11847
Standof
fs -
Top
Qty
. 4 req.
11
864i
Strip Protector
Qty
. 3 req.
18320
Touch-up Paint
71479
Installation Instructions & Owner's Manual
12538
Heatilator • CL36D, CR36D • 12538 • Rev T • 09/08
