36
3 in. (76 mm)
Min. Opening Height
Min. Base Dim
Min. Height
above radiation
shield
Min.
Base Dim
3 in. (76 mm) Min.
Radiation Shield Height
from top of Chase
Min. Opening Width
Minimum
Opening
Height
Minimum
Base Dimension
Min. Opening Width
Min. Base Dimension
Minimum
Height above
Radiation Shield
Chase Top
Radiation Shield
3 in. (76 mm)
Radiation
Shield Height
Termination
Cap
Roofed Style Shroud (radiation shield required)
Mailbox Style Shroud (radiation shield required)
Figure 10.3 Mailbox Style Shroud Dimensions
Figure 10.4 Roofed Style Shroud Dimensions
Heatilator • CL36D, CR36D • 12538 • Rev T • 09/08
TS345 TR342 TR342/344TV
Min. Base Dims.
in N/A 26-1/2 x 28 28 x 30
mm N/A 673 x 711 711 x 762
Min. Height Above Radiation Shield
in N/A 21-1/4 20-1/2
mm N/A 540 521
Min. Opening Width
in N/A 20-1/2 x 22 22 x 24
mm N/A 521 x 559 559 x 610
TS345/445
TR342/344
TR442/444
TR342/344TV
Min. Base Dims.
in N/A 27 x 27 27 x 27
mm N/A 686 x 686 686 x 686
Min. Height Above Radiation Shield
in N/A 16 16
mm N/A 406 406
Min. Opening Width
in N/A 21 21
mm N/A 533 533
Min. Opening Height
in N/A 12 12
mm N/A 305 305
