PCI-X Non-Hot Plug Riser

Expansion Slots

Slot

Number

Bus Speed

Bus Number

Device

Number

Hot Plug

PCI Voltage

64-bit/133MHz PCI-X

3.3 Volt

64-bit/100MHz PCI-X

3.3 Volt

64-bit/100MHz PCI-X

3.3 Volt

NOTE:

NOTE: The Smart Array P600 Array Controller (SAS) with 256MB BBWC installed in Slot 1 on SAS
models.
NOTE:

NOTE:

NOTE: Universal cards are supported.

PCI-X Hot Plug Riser (Optional)

64-bit/133MHz PCI-X

3.3 Volt

64-bit/100MHz PCI-X

yes

3.3 Volt

64-bit/100MHz PCI-X

yes

3.3 Volt

NOTE:

NOTE: Universal cards are supported

PCI Express Non-Hot Plug Riser

PCI Express Non-Hot Plug Riser
(Optional on U320 SCSI Models only)

PCI Express x4

NOTE:

NOTE: x8 cards are supported but will run at x4 speeds.
*NOTE:

NOTE:

NOTE: Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment

number.
**NOTE:

NOTE:

NOTE: Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest

Device ID by bus (starting with the lowest bus).

Storage Controller

Storage Controller
One of the following
depending on model

Smart Array 6i Controller (integrated on system board)

Smart Array P600/256 BBWC Controller (SAS Models)

Storage

Diskette Drive

1.44 MB Diskette Drive (optional on some models)

Optical Drive

24x IDE CD-ROM (IDE DVD-ROM included on High performance models)

Hard Drives

None Standard

NOTE:

NOTE: U320 SCSI models can be operated in single channel or dual
channel (2/4 split). SCSI configuration kit (364471-B21) is required for dual
channel configurations.

Maximum Internal

Maximum Internal
Storage Type

Storage Type

Hot Plug U320 SCSI

1.8TB

6 x 300GB with standard internal hot plug SCSI
drive cage

Hot Plug SAS

1.168TB

8 x 146GB with standard internal hot plug small
form factor SAS drive cage
