System Unit

Dimensions

Dimensions (HxWxD)
(with feet/bezel)

3.38 x 17.54 x 26.01 in (8.59 x 44.54 x 66.07 cm)

Weight

Weight(approximate)

Maximum

60 lb (27.22 kg)

No drives:

47.18 lb (20.41 kg)

Input Requirements

Input Requirements
(per power supply)

Rated Input Voltage

100-132 VAC, 200-240 VAC

Rated Input Current

7.5A (100VAC), 3.8A (200VAC)

Rated Input Frequency

50 to 60 Hz

Rated Input Power

735 W

BTU Rating

2508 BTU/HR

Power Specifications

To review typical system power ratings use the Active Answers Power
Calculator which is available via the online tool located at URL:

http://h30099.www3.hp.com/configurator/powercalcs.asp

To drill down to calculators:
- Click on: "ProLiant Servers"
- Click on the Server of interest. Example: DL380 G4
- Click on: "Power Calculator" link. (You may need to scroll down to see it.)

SCSI Connectors

One external VHDCI connector

NOTE:

NOTE: External VHDCI not included on SAS Models

Power Supply Output

Power Supply Output
Power

Power

Power
(per power supply)

Rated Steady-State Power 575W

Maximum Peak Power

575W

Temperature Range

NOTE:

NOTE: All temperature
ratings shown are for sea
level. An altitude derating
of 1 C° per 300 m (1.8 FR
per 1000 ft) to 3048 m
(10,000 ft) is applicable.
No direct sunlight allowed.

Operating

50° to 95° F (10° to 35° C)

Shipping

-40° to 158° F (-40° to 70° C)

Maximum Wet Bulb

Maximum Wet Bulb
Temperature

Temperature

82.4° F (28° C)

Relative Humidity

Relative Humidity
(non-condensing)

NOTE:

NOTE: Storage maximum
humidity of 95% is based
on a maximum
temperature of 45°C
(113°F). Altitude maximum
for storage corresponds to
a pressure minimum of 70
kPa.

Operating

10% to 90%

Shipping

5% to 95%

QuickSpecs

HP ProLiant DL380 Generation 4 (G4)

Technical Specifications

DA - 12028 Worldwide — Version 58 — February 12, 2007
