Page 44
SFF SAS Hot Pluggable Drives
Quantity
Supported
Position
Supported
Controller
146GB 3G SAS 10K SP
72GB 3G SAS 10K SP
72GB 3G SAS 15K SP
36GB 3G SAS 10K SP
36GB 3G SAS 15K SP
Up to 18
1-18
HP Smart Array P600/256 BBWC Controller
NOTE: SAS Drives supported by the HP ProLiant ML570 G3 SAS Models only or with HP ProLiant ML570 G3 model
upgraded SAS Drive Cage Option Kit.
External Storage
Quantity
Supported
Position
Supported
Host Controller or Adapter
Modular Smart Array 30
Family
Up to 28
External
Smart Array 6402/128 Controller
Smart Array 6404/256 Controller
Smart Array 642 Controller
Modular Smart Array 50
Enclosure
Up to 2
External
HP Smart Array P600/256 BBWC Controller
Modular Smart Array
1000
Please see the
Modular Smart
Array 1000
QuickSpecs
below to
determine
configuration
requirements
External
Please see the Modular Smart Array 1000 QuickSpecs for the
latest list of supported HBAs:
Modular Smart Array
1500 cs
Please see the
Modular Smart
Array 1500 cs
QuickSpecs
below to
determine
configuration
requirements
External
Please see the Modular Smart Array 1500 cs QuickSpecs for
the latest list of supported HBAs:
Maximum Storage Capacity – (ML570 10 Bay Hot Plug Ultra320 SCSI Drive Cage, 4 channel controller in 4 full-length
PCI-X slots & MSA30 enclosures)
Internal
3.00TB ((10 x 300GB) Ultra320 SCSI Drives)
External
67.20TB hot plug SCSI storage (16 x (14 x 300GB Ultra320 SCSI Drives))
Total
70.20TB
Maximum Storage Capacity SAS Models – (ML570 SFF SAS Drive Cage, 8 port SAS controller in 4 slots & MSA50
enclosures)
Internal
2.628TB ((18 x 146GB) SFF SAS Drives)
External
11.680TB hot plug SFF SAS storage (4 x (20 x 146GB SFF SAS Drives))
Total
14.308TB
Tape Drives, Tape Autoloaders, & Tape Libraries
NOTE: For an up-to-date listing of the latest O/S Support details for each of the Tape Drives listed below, please see the
QuickSpecs
HP ProLiant ML570 Generation 3
Storage
DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007
Page 44
