Wireless Router User Guide

Properties

• Destination Network - The network address of the remote LAN

segment. For standard class "C" LANs, the network address is
the first 3 fields of the Destination IP Address. The 4th (last)
field can be left at 0.

• Network Mask - The Network Mask for the remote LAN

segment. For class "C" networks, the default mask is
255.255.255.0

• Gateway IP Address - The IP Address of the Gateway or

Router which the Wireless Router must use to communicate with
the destination above. (NOT the router attached to the remote
segment.)

• Metric - The number of "hops" (routers) to pass through to

reach the remote LAN segment. The shortest path will be used.
The default value is 1.

Buttons

Save

Save the RIP setting. This has no effect on the Static Routing Table.

Add

Add a new entry to the Static Routing table, using the data shown in
the "Properties" area on screen. The entry selected in the list is
ignored, and has no effect.

Update

Update the current Static Routing Table entry, using the data shown
in the "Properties" area on screen.

Delete

Delete the current Static Routing Table entry.

Clear Form

Clear all data from the "Properties" area, ready for input of a new
entry for the Static Routing table.

Generate Report

Generate a read-only list of all entries in the Static Routing table.

Configuring Other Routers on your LAN

It is essential that all IP packets for devices not on the local LAN be passed to the Wireless
Router, so that they can be forwarded to the external LAN, WAN, or Internet. To achieve this,
the local LAN must be configured to use the Wireless Router as the Default Route or Default
Gateway.

Local Router

The local router is the Router installed on the same LAN segment as the Wireless Router. This
router requires that the Default Route is the Wireless Router itself. Typically, routers have a
special entry for the Default Route. It should be configured as follows.

Destination IP Address

Normally 0.0.0.0, but check your router documentation.

Network Mask

Normally 0.0.0.0, but check your router documentation.

Gateway IP Address

The IP Address of the Wireless Router.

Metric
