Setup
17
Options
Mode Select the desired mode:
• g & b - Both 802.11.g and 802.11b Wireless stations will be able
to use the Wireless Router.
• g only - Only 802.11g Wireless stations can use the Wireless
Router.
• b only - Only 802.11b connections are available. 802.11g Wire-
less Stations will only be able to use the Wireless Router if they
are fully backward-compatible with the 802.11b standard.
Channel No. This selection determines which operating frequency will be used. The
channel list changes according to the selected region.
Select the desired channel. Adjacent Access Points should use different
channels to avoid interference.
Broadcast SSID If Enabled, the SSID will broadcast its name to all Wireless Stations.
Stations which have no SSID (or a "null" value) can then adopt the
correct SSID for connections to this Access Point.
WEP data
encryption
• WEP status - This will display "Enabled" or "Disabled"
• Configure WEP - Click this button to access the WEP sub-
screen, and the WEP settings. Show the WEP status.
Access Point
Enable Access
Point
• If Enabled, wireless stations will be able to locate and use this
Access Point.
• If Disabled, the wireless interface is disabled, and will neither
transmit nor receive wireless traffic.
• The Wireless (WLAN) LED on the front panel will remain OFF if
the Wireless interface is disabled.
Allow LAN
access by …
• All Wireless Stations - All wireless stations can use the access
point to access your LAN.
• Selected Wireless stations only - Only selected wireless stations
access your LAN. To select the required wireless stations, click
the "Select Stations" button.
Allow Internet
access by …
• All Wireless Stations - All wireless stations can use the access
point to access the Internet.
• Selected Wireless stations only - Only selected wireless stations
use the access point to access the Internet. To select the required
wireless stations, click the "Select Stations" button.
Buttons
Configure WEP Click this button to view the WEP sub-screen.
Select Stations Click this button to select the required PCs.
Save Save the data on screen.
Cancel The "Cancel" button will discard any data you have entered since the
last "Save" operation.
