HP iPAQhx HX2490b - Manual (Page 4)

Other interfaces Other interfaces Other interfaces Other interfaces IrDA (SIR) IrDA (SIR) IrDA (SIR) IrDA (SIR)
USB 2.0 Client USB 2.0 Client USB 2.0 Client USB 2.0 Client – supported via HP standard 22-pin cradle interface
Serial RS232
Serial RS232 Serial RS232 Serial RS232 – supported via HP standard 22-pin cable interface (cable must be purchased separately)
NOTE: NOTE: NOTE: NOTE: Some HP authorized options may not be supported. See
http://www.hp.com/go/ipaqaccessories .
SD Slot SD Slot SD Slot SD Slot Support 1-bit SDIO and 4-bit SD/MMC type memory standard
CF Slot CF Slot CF Slot CF Slot 1 Type II
Power Supply Power Supply Power Supply Power Supply Battery Battery Battery Battery Removable/rechargeable 1440 mAh Lithium-lon (user changeable).
Optional extended 2880 mAh Lithium-lon battery available for purchase
separately (
http://www.hp.com/go/ipaqaccessories ).
AC Power AC Power AC Power AC Power AC Input: 100~240 Vac, 50/60 Hz, AC Input current: 0.3 Aac max
Output Voltage: 5Vdc (typical), Output Current: 2A (typical)
NOTE: NOTE: NOTE: NOTE: Battery run time varies based on the usage pattern of an individual user and the configuration of
the handheld. Use of internal wireless capabilities and backlight will significantly decrease battery run
time.
AC Adapter AC Adapter AC Adapter AC Adapter Dimensions Dimensions Dimensions Dimensions (H x W xD) 3 x 1.9 x 1.8 in (76 x 48 x 44 mm – including prongs), (may vary by model)
Cord Length Cord Length Cord Length Cord Length (approx.) 6 ft (1.83 m)
Power Supply Ratings Power Supply Ratings Power Supply Ratings Power Supply Ratings Voltage Range 100 to 240 V Switching
Input Current 0.3 Aac
Input Frequency 50 to 60 Hz
Output Voltage 5 VDC
Output Current 2 Amp
System Unit System Unit System Unit System Unit Dimensions Dimensions Dimensions Dimensions (H x W x D) 4.71 x 3.01 x .65 in (119.4 x 76.6 x 16.3mm)
Weight Weight Weight Weight 5.8 oz (164.4 g)
Operating Temperature Operating Temperature Operating Temperature Operating Temperature 32° to 104° F (0° to 40° C)
Storage Temperature Storage Temperature Storage Temperature Storage Temperature -4° to 140° F (-20° to 60° C)
Operating Humidity Operating Humidity Operating Humidity Operating Humidity 90% RH
Regulatory Marks Regulatory Marks Regulatory Marks Regulatory Marks Electrical Electrical Electrical Electrical FCC Class B, UL or CSA NRTL
Safety Safety Safety Safety C-UL, NOM
Design Features Design Features Design Features Design Features 4 programmable application quick-launch buttons, 5-way navigation button, touch-sensitive display for
stylus or fingertip, voice record button, microphone and speaker, rubber sides for comfortable grip
QuickSpecs
HP iPAQ hx2490 Pocket PC HP iPAQ hx2490 Pocket PC HP iPAQ hx2490 Pocket PC HP iPAQ hx2490 Pocket PC
Standard Features
DA - 12293 North America — Version 7 — September 26, 2007 Page 4
