CHAPTER 4
DMX Programming
Roadster Orbital Head System User Manual 33
Control Function
The Control parameter provides access to a number of Power Hub and Projector commands
from the control desk.
Parameter DMX Value
Control Option Description
Shutter Control
0-255
0-9 Safe Disables all Control settings for normal operation.
10-19 Pan & Tilt MSpeed Off Sets Pan & Tilt MSpeed off.
0
20-28 Display Off Sets display to off.
30-38 Display Dim Dims display characters.
40-48 Display Bright Brightens the display characters.
60-68 Home All Remotely homes the Orbital Head pan and tilt functions.
70-78 Home ILS
Remotely detects the projector’s intelligent lens system
after a lens change and homes the focus and zoom .
80-88 Lamp On Remotely restrikes the fixture’s lamp.
90-98 Lamp Off Remotely extinguishes the fixture’s lamp.
100-105 ILS On
Remotely turns on the projector’s intelligent lens system
on and allows focus and zoom control via RS-232. ILS off
is the projector’s initial default. Use this option when the
ILS gets inadvertently turned off, or if the projector is
replaced.
120-130 Shutdown
Shuts down the fixture. The lamp is off, power to the
motors is disabled, and the display reads [
SHUTDOWN].
Homing the fixture brings it back into operation.
0-255
141-150 Horizontal offset right These options are live so that the shutter can be open and
you can center the image on the mirror. The commands
work like a remote control. Issue a left command and the
lens moves left until a stop is issued, or the lens reaches
the end of travel. Likewise with up, down and right.
These commands are best written as presets that can
issued once rather then live dimming or scrolling from
command to command.
151-160 Horizontal offset stop
161-170 Horizontal offset left
171-180 Vertical offset up
181-190 Vertical offset stop
191-200 Vertical offset down
