CHAPTER 3
Operation and Maintenance
Roadster Orbital Head System User Manual 29
Power Hub Maintenance
Replacing the Power Hub Fuse
To replace a fuse:
1. Disconnect power to the power supply hub.
2. Remove the three screws on the back of the power supply hub and lift the cover.
3. Locate the fuse on the bridge over the power supply.
4. Replace the Power supply fuse with the following:
Replacement Parts
The Orbital Head System has no user-serviceable parts. To return it for servicing, call your
High End Systems dealer/distributor for a Return Material Authorization (RMA) number. High
End Systems cannot accept any goods shipped without an RMA number. For more
information, see “Warranty Information” on page v.
Cleaning the Mirrors
If the mirrors become dirty, clean them using a mild glass cleaner (containing no ammonia)
and a soft, lint-free cotton cloth.
Warning: Disconnect power before servicing.
This fixture must only be serviced by qualified
personnel. The following information is intended
to assist qualified personnel only.
Replace
fuses with the specified type and rating only.
Fuse Type and Rating Manufacturer High End Systems p/n
2.5 A, 250 V, Slow Blow Littelfuse 215 02.5 90403027
