CHAPTER 2
Setup and Configuration

Roadster Orbital Head System User Manual

To set the DMX start channel on the Power Hub:

1. Press the Menu button to unlock the menu system or to move back up the system to the

top level menus.

DMX ADDRESS MENU

is the first menu item at the top level.

1. Press the Enter button to select. The display will show

SET DMX START

CHANNEL:###.

The display will show the start channel currently assigned to the fixture.

2. Use the up and down arrows on the Navigation button to select a new DMX start channel,

if necessary. The display will flash a new option ready for selection.

Note: The last valid Start channel for a fixture on a DMX link is based on

the channel range required by fixture’s module configuration. The
last valid Start channel for the Orbital Head System 501 (512 –12+1).

3. Press the Enter button to accept the new DMX start channel.

Note: If the Enter button is not pressed, the old value will remain selected

after exiting the menu.

For more information on navigating the menu system, see The Power Hub Menu Display on
page 17.
