handshake. Enter a value between 0 and 2432.
Fragment Threshold: The threshold (number of bytes) for the fragmentation boundary for
directed messages. It is the maximum data fragment size that can be sent. Enter a value
between 256 and 2432.
DTIM: This value is between 1 and 255, indicates the interval of the Delivery Traffic Indication
Message (DTIM).
6.3.2 Multiple SSIDs Settings
SSID: The SSID is a unique name to identify the ADSL Router in the Wireless LAN. Wireless
Clients associating to the ADSL Router must have the same SSID. The define SSID name is
Default_WLAN.
Broadcast SSID: Select No to hide the SSID such that a station can not obtain the SSID through
passive scanning. Select Yes to make the SSID visible so a station can obtain in the SSID
through Passive scanning.
Channel ID: The range of radio frequencies used by IEEE 802.11b/g wireless devices us called
a channel.
[Authentication Type]
WEP (Wired Equivalent Privacy) encrypts data frames before transmitting over the wireless
network. Select Disable to allow all wireless computers to communicate with the access points
without any data encryption. Select 64-bit WEP or 128-bit WEP to use data encryption.
Key#1~Key#4 The WEP keys are used to encrypt data. Both the ADSL Router and the wireless
clients must use the same WEP key for data transmission. If you chose 64-bit WEP, then enter
any 10 hexadecimal digits (“0-9”, “A-F”) preceded by 0x for each key (1-4). If you choose 1280bit
WEP, then enter 26 hexadecimal digits (“0-9”, “A-F”) preceded by 0x for each key (1-4). The
values must be set up exactly the same on the Access Points as they are on the wireless client
stations. The same value must be assigned to Key 1 on both access point (your ADSL Router)
and the client adapters, the same value must be assigned to Key 2 on both access point and the
client stations and so on, for all four WEP keys.
WPA-PSK Wi-Fi Protected Access, pre-shared key. Encrypts data frames before transmitting
over the wireless network.
Pre-shared Key is used to encrypt data. Both the ADSL Router and the wireless clients must
use the same WPA-PSK Key for data transmission.
6.3.3 MAC Address Filter
You can allow or deny a lust of MAC addresses associated with the wireless stations access to
the ADSL Router.
48
Status: Use the drop down list box to enable or disable MAC address filtering.
