27
INB100014-1 (Rev 19)
IND100129-42
Specifications - JH 15T05 MMC
A P P R O V A L S & C E R T I F I C A T E S
On front bezel:
• Power On/Off (push button)
• Brightness Control
• Power LED, HD Led and Reset button
Behind hatch:
• USB 2.0 connector(s)
Available Mechanical Options:
User Controls:
Input/Output Connectors:
Environmental Considerations:
Accessories:
• JH 15TSV : Sun visor *
• JH 15TBRMMC : Bracket *
• Touch Screen **
* Option: Standard or custom logo and color
** Option: Factory mounted
• Operating : Temperature -15 deg. C to +55 deg. C
Humidity 30% to 90% (non condensing)
• Storage : Temperature -20 deg. C to +70 deg. C
Humidity 10% to 90% (non condensing)
• IP Rating : EN60529 (IP66) (Applies for flush mounting)
Available Technical Options:
Power Specifications:
Physical Dimensions:
• 412 (W), 345 (H), 83.5 (D) mm
• Weight: 8 kg (approx)
TFT Characteristics:
TFT Technology:
• 15.0 inch viewable image size
• Color Active Matrix LCD Module
• a-Si Thin Film Transistor (TFT)
• Pixel number : 1024 x 768
• Pixel pitch (RGB) : 0.297 (H) x 0.297 (V) mm
• Response Time : 25 ms (typical), “black” to “white”
• Contrast Ratio : 400:1 (typ)
• Light Intensity : 250 cd/m2 (typical)
• Viewable Angle : +/- 85 deg. (min) (Up/Down/Left/Right)
: (@ CR > 10)
• Active Display Area : 304.1 (H) x 228.1 (V) mm
• Max Colors : 16.7 millions
This product have been tested / type approved by the following classification societies: (1=AC Version, 2=DC Version)
EN60945 4th (IEC945 4th) (1,2) ClassNK - Nippon Kaiji Kyokai (1,2) DNV - Det Norske Veritas (1,2)
IACS E10 (1,2) GL - Germanischer Lloyd (1,2) BV - Bureau Veritas (1,2)
ABS - American Bureau of Shipping (1,2) LRS - Lloyd's Register of Shipping (1,2) RS - Russian Maritime Register of Shipping (1,2)
Power Supply Options:
• 115 & 230VAC - 50 / 60Hz : Model JH 15T05 MMC A1
• 24 VDC : Model JH 15T05 MMC A2
Power Consumption:
• Operating : 100W (max) (Configuration depending)
: 65W (typ) (Max backlight & high CPU load)
Safety Considerations:
Even although the test conditions for bridge units provide for a maximum
operating temperature of 55°C, continuous operation of all electronic
components should, if possible, take place at ambient temperatures of only
25°C. This is a necessary prerequisite for long life and low service costs.
Function Back side Inside Front
Ethernet Lan/GBLan 2 x RJ-45
PC/104 Slot 1 x PC/104 Slot
Keyboard 1 x PS/2
Mouse 1 x PS/2
Compact Flash 1 x CF Socket
COM 1 1 x DB9M
COM 2 1 x DB9M
COM 3 1 x DB9M
COM 4 1 x DB9M
LPT1 1 x DB25F
USB2.0 3 x USB 1 x USB
AC Power Std IEC inlet (Odd version models)
DC Power DC Screw terminal (Even version models)
RGB Out 1 x HD-15F
TV Out Composite RCA (depends on model)
Line In/Out 3.5mm mini jack (depends on model)
Mic In 3.5mm mini jack (depends on model)
Compass Safe Distance: JH 15T05 MMC Standard: 125cm Steering: 80cm
Miscellaneous Options:
• Audio AC97 Compliant : Line In/Out, Mic In, Speaker Out
• TV-Out : 1 x Composite (Depends on model)
• Processor : Up to 2.0 GHZ
• Memory : Up to 1GB
Computer Specifications:
• Installed OS : None, please specify when ordering
• Processor : Intel® Pentium®M 1.1GHz, Low Voltage
• Cache / PCI Clock : 1MB Level 2 Cache / 400 MHz BUS
• System Chipset : Intel® 82855GME
• BIOS : Phoenix 2Mbit Flash, Supports ACPI
• PC/104 Slot : 1 x PC/104 with ISA Support
• Memory Slot : 1 x SODIMM with ECC, from 256MB->1GB
• Graphics Chip : Intel® 82855GME (Integrated/250MHz)
• IDE Controller : 1 x IDE Ports, Ultra DMA33/66/100
• Storage : 1 x Automotive 30GB, 2.5" IDE, 4200 RPM
• Compact Flash : 1 x CF Socket with Eject (Type I & II)
• Parallel Port (LPT) : 1 x EPP/ECP Port
• Primary Ethernet : 1 x 10/100 Mbps
• Secondary Ethernet : 1 x 10/100/1000 Mbps
• Serial Ports : 4 x RS232/RS422/RS485 (fully isolated)*
• USB Ports : 4 x USB (2.0 compliant, 480Mbps)
• Keyboard/Mouse : 2 x PS/2
• Supported TFT Res. : From 640 x 480 up to 2048 x 1536**
• RGB OUT Res : From 640 x 480 up to 1600 x 1200
* only in RS422/485 mode
** Optimal 1:1 resolution and recommended is 1024 x 768 @ 60 Hz.
** If resolutions is set above 1:1, desktop scrolling mode will be used.
M E C H A N I C A L D E S C R I P T I O N T E C H N I C A L D E S C R I P T I O N
Note: All specifications are subject to change without prior notice!
