Page 7
X
-Arrayy Install
TM
Xi-1122/85 Loudspeaker System
7
X-Array Install
TM
Xi-1122/85 Loudspeaker System
Figure 6— Impedance
The impedance of each frequency band of
the system was measured in an anechoic en-
vironment.
LF
HF
Figure 7— Wiring Diagram
The wiring diagram of each frequency band
of the system is shown.
Figure — Dimensions
