have other rights which vary from state to
state.
Electro-Voice Speakers and Speaker Sys-
tems are guaranteed against malfunction due
to defects in materials or workmanship for a
period of five (5) years from the date of origi-
nal purchase. The Limited Warranty does not
apply to burned voice coils or malfunctions
such as cone and/or coil damage resulting
from improperly designed enclosures.
Electro-Voice active electronics associated
with the speaker systems are guaranteed for
three (3) years from the date of original pur-
chase. Additional details are included in the
Uniform Limited Warranty statement.
Electro-Voice Accessories are guaranteed
against malfunction due to defects in mate-
rials or workmanship for a period of one (1)
year from the date of original purchase. Ad-
ditional details are included in the Uniform
Limited Warranty statement.
Electro-Voice Flying Hardware (including
enclosure-mounted hardware and rigging ac-
cessories) is guaranteed against malfunction
due to defects in materials or workmanship
for a period of one (1) year from the date of
original purchase. Additional details are in-
cluded in the Uniform Limited Warranty
statement.
For warranty repair, service information, or
a listing of the repair facilities nearest you,
contact the service repair department at:
616/695-6831 or 800/685-2606.
For technical assistance, call: 800/234-6831.
Specifications subject to change without
notice.
Architects' And Engineers'
Specifications
The loudspeaker speaker system shall be a
two-way biamped system with performance
controlled by a variety of dedicated elec-
tronic control units. The loudspeaker sys-
tem shall have a 305-mm (12-inch) direct-
radiating driver with an 8-ohm, 63.5-mm
(2.5-inch) voice coil constructed of alumi-
num wire, and shall be capable of a 300-watt
shaped pink-noise signal with a 6-dB crest
factor for 8 hours (as per ANSI/EIA RS-426-
A 1980). The loudspeaker system shall have
a 35.56-mm (1.4-inch) exit compression
driver mounted on a high-frequency horn.
The compression driver shall have
76.2-mm (3.0-inch) diameter, .0015-inch
thick titanium dome and an 16-ohm nomi-
nal, 76.2-mm (3.0-inch) diameter voice coil
constructed of aluminum wire, and which
shall be capable of handling a 75-watt, 1,480-
to 20,000-Hz pink-noise signal with a 6-dB
crest factor for 8 hours (as per ANSI/EIA
RS-426-A 1980 standard). The high-fre-
quency horn shall be of the constant-direc-
tivity type and shall produce a nominal hori-
zontal beamwidth (6-dB-down angle) of 80°
from 2,000 to 20,000 Hz and a nominal ver-
tical beamwidth of 55° from 1,600 to 20,000
Hz. The loudspeaker system enclosure
shall be constructed of 18-mm thick,
13-ply birch plywood, trapezoidal in shape,
forming a 30° wedge, and shall have a
vinyl-clad steel-grille system.
The Xi-1122/85 system shall be used with
recommended control systems and shall have
a two-way crossover circuit with fourth-
order Linkwitz-Riley filters, equalization,
time delay and protection circuitry. When
used with the electronic control unit, the
loudspeaker system shall have a flat on-axis
frequency response from 60 to 16,000 Hz.
The loudspeaker enclosure dimensions shall
be 589 mm (23.0 in.) high, 375 mm (14.75
in.) wide (front), 356 mm (14.0 in.) wide
(back) and 356 mm (14.0 in.) deep and shall
weigh 31.36 kg (69 lb). The system shall
incorporate a two-point rigging system that
will accept New Haven NH32101-2 double-
stud ring fittings and the New Haven
NH8192-2S and Ancra 42456-10 single-stud
fittings.
The loudspeaker shall be Electro-Voice
Xi-1122/85 (and its variants).
Uniform Limited Warranty
Electro-Voice products are guaranteed
against malfunction due to defects in mate-
rials or workmanship for a specified period,
as noted in the individual product-line
statement(s) below, or in the individual prod-
uct data sheet or owner’s manual, beginning
with the date of original purchase. If such
malfunction occurs during the specified pe-
riod, the product will be repaired or replaced
(at our option) without charge. The product
will be returned to the customer prepaid.
Exclusions and Limitations: The Limited
Warranty does not apply to: (a) exterior fin-
ish or appearance; (b) certain specific items
described in the individual product-line
statement(s) below, or in the individual prod-
uct data sheet or owner’s manual; (c) mal-
function resulting from use or operation of
the product other than as specified in the
product data sheet or owner’s manual; (d)
malfunction resulting from misuse or abuse
of the product; or (e) malfunction occurring
at any time after repairs have been made to
the product by anyone other than
Electro-Voice Service or any of its autho-
rized service representatives. Obtaining War-
ranty Service: To obtain warranty service, a
customer must deliver the product, prepaid,
to Electro-Voice Service or any of its autho-
rized service representatives together with
proof of purchase of the product in the form
of a bill of sale or receipted invoice. A list of
authorized service representatives is avail-
able from Electro-Voice Service at 600 Cecil
Street, Buchanan, MI 49107 (800-234-6831
or FAX 616-695-4743). Incidental and Con-
sequential Damages Excluded: Product re-
pair or replacement and return to the cus-
tomer are the only remedies provided to the
customer. Electro-Voice shall not be liable
for any incidental or consequential damages
including, without limitation, injury to per-
sons or property or loss of use. Some states
do not allow the exclusion or limitation of
incidental or consequential damages so the
above limitation or exclusion may not apply
to you. Other Rights: This warranty gives
you specific legal rights, and you may also
