PanelMate Operator Interface
Legacy Products Spare Parts
Table 59. PanelMate ePro (75xx Series) Spare Parts
Table 60. PanelMate Power Series 2000 Spare Parts
Table 61. PanelMate Power Series 3000 Spare Parts
ᕃ Contact factory.
Description Catalog
Number Price
U.S. $
7.7" Color DSTN Display Assembly for 7575T-8 Series
8.4" Color TFT Display Assembly for 7585K-8 and 7585T-8 Series
10.4" Color TFT Display Assembly for 7585K-10 and 7585T-10 Series
63-00678
63-00544
63-00778 1,159.00
2,514.00
2,838.00
Keypad with Window for 7585K-8 Series 63-00796 727.00
Touchscreen for 7575T-8 Series (gaskets 32-01682 and 32-02437 required) 63-00837 593.00
Gasket for Touchscreen (between touchscreen and front panel)
for 7575T-8 Series
Gasket for Touchscreen (between touchscreen and display)
for 7575T-8 Series
32-01682
32-02437
33.50
27.25
Touchscreen for 7585T-8 Series (gaskets 32-01682 and 32-02208 required) 63-00832 593.00
Gasket for Touchscreen (between touchscreen and front panel)
for 7585T-8 Series
Gasket for Touchscreen (between touchscreen and display)
for 7585T-8 Series
32-01682
32-02208
33.50
27.25
Keypad for 7585K-10 Series (does not include window)
Plexi-Glass Window for 7585K-10 Series 63-00805
32-02151 855.00
25.75
Touchscreen for 7585T-10 Series 63-00585 494.00
Gasket for Touchscreen for 7585T-10 Series
(between touchscreen and display)
32-02145 21.00
Front Panel Assembly for 7585K-8 Series 91-01985 430.00
Front Panel Assembly for 7575T-8 and 7585T-8 Series 91-01494 127.00
Front Panel for 7585T-10 Series (gaskets 32-02144 and 32-02145 required)
Gasket for Front Panel for 7585T-10 Series
Gasket for Touchscreen for 7585T-10 Series 32-02444
32-02144
32-02145 582.00
21.00
21.00
Backlight Kit for 7585K-8 and 7585T-8 Series
Backlight Kit for 7585K-10 and 7585T-10 Series 87-02455
87-02379 232.00
232.00
Ship Kit for 7585K-8 Series
Ship Kit for 7575T-8 and 7585T-8 Series
Ship Kit for 7585T-10 Series 86-00086
86-00083
86-00085 47.25
47.25
47.25
ISA 1 Port PanelMate PC Adapter D712-DHP-ISA 2,130.00
Description Catalog
Number Price
U.S. $
Display Assembly for 24xx
Display Assembly for 26xx 91-01430
91-01425 1,206.
1,206.
PanelMate Power Series Upgrade Kit (adds high capacity, dynamic
graphics, advanced trending and Modbus enabler) PMUPGRADE 273.
Membrane Keypad (4-position) for 24xx, 26xx, 27xx 63-00395 317.
Description Catalog
Number Price
U.S. $
Keypad with Window for 39xx
Touchscreen for 39xx 63-00743
63-00285 1,267.
927.
PanelMate Power Series Upgrade Kit (adds high capacity, dynamic
graphics, advanced trending and Modbus enabler) PMUPGRADE 273.
Backlight Kit for 37xx
Backlight Kit for 39xx 87-01216
ᕃ
232.
—
