Eaton Electrical CA04801001E - Manual (Page 34)

March 2008
34
For more information visit: www.eaton.com CA04801001E
Operator Interface Products
PanelMate Operator Interface
Connectivity: Utilities, Interfaces & Cables
Omron Connectivity
Omron Communication Cables
PLC Interface Cables for PanelMate Power Pro 1100, 1700,
3000, 5000 or ePro
One 15-foot (4.6 m) cable, unless otherwise stated, for commu-
nications between a PanelMate1100, 1700, 3000, 5000 or
ePro unit serial port and the PLC communications port using
D-Shell connectors. Cables used with PanelMate ePro require
a DB9(M)/DB9(F) converter (converts DB9(M) to DB9(F)).
Table 46. PLC Interface Cables for PanelMate Power Pro 1100, 1700,
3000, 5000 or ePro
PROFIBUS DP Connectivity
PROFIBUS DP Interface
This PROFIBUS DP Slave Adapter interface provides com-
munications between a PanelMate operator interface and a
PROFIBUS network without requiring any additional com-
munications modules. A maximum of one interface can be
installed on each PanelMate unit.
Table 47. PROFIBUS DP Interface
Siemens Connectivity
PLC Interface Cables for PanelMate Power Pro 1100, 1700,
3000, 5000 or ePro
One 15-foot (4.6 m) cable, unless otherwise stated, for commu-
nications between a PanelMate 1100, 1700, 3000, 5000 or
ePro unit serial port and the PLC communications port using
D-Shell connectors. Cables used with PanelMate ePro require
a DB9(M)/DB9(F) converter (converts DB9(M) to DB9(F)).
Table 48. PLC Interface Cables for PanelMate Power Pro 1100, 1700,
3000, 5000 or ePro
Simatic TI Connectivity
Simatic TI Communication Cables
PLC Interface Cables for PanelMate Power Pro 1100, 1700,
3000, 5000 or ePro
One 15-foot (4.6 m) cable, unless otherwise stated, for commu-
nications between a PanelMate 1100, 1700, 3000, 5000 or
ePro unit serial port and the PLC communications port using
D-Shell connectors. Cables used with PanelMate ePro require
a DB9(M)/DB9(F) converter (converts DB9(M) to DB9(F)).
Table 49. PLC Interface Cables for PanelMate Power Pro 1100, 1700,
3000, 5000 or ePro
Square D Connectivity
Square D Communication Cables
PLC Interface Cables for PanelMate Power Pro 1100, 1700,
3000, 5000 or ePro
One 15-foot (4.6 m) cable, unless otherwise stated, for commu-
nications between a PanelMate 1100, 1700, 3000, 5000 or
ePro unit serial port and the PLC communications port using
D-Shell connectors. Cables used with PanelMate ePro require
a DB9(M)/DB9(F) converter (converts DB9(M) to DB9(F)).
Table 50. PLC Interface Cables for PanelMate Power Pro 1100, 1700,
3000, 5000 or ePro
Description Catalog
Number Price
U.S. $
C Series (RS-232)
CV Series (RS-232) OM21
OM22 125.
125.
C Series (RS-422) Cable
CV Series (RS-422) Cable OM23A
OM24A 125.
125.
CS/CQ Series (RS-232) Cable OM25 125.
Description Catalog
Number Price
U.S. $
PROFIBUS DP Slave I/O Interface
For all PanelMate Power Pro 1100, 1700,
3000, 5000 1247 1,211.
Description Catalog
Number Price
U.S. $
Siemens (RS-232)
Siemens S7 HMi Cable SI21
SI22 125.
125.
Description Catalog
Number Price
U.S. $
TI 500, 305 (RS-232)
TI 405 (RS-232)
TI 545 (RS-232) TI21
TI22
TI23 125.
125.
125.
TI 305-02DM, TI 405 DCM (RS-422) Cable
TI 545-1101 (RS-422) Cable
TI 545-12102, 1104, 1105 Cable TI25A
TI26A
TI27A 125.
125.
125.
Description Catalog
Number Price
U.S. $
PLC Processor Cable
NIM Network Interface Module Cable SD21A
SD22A 125.
125.
Discount Symbol . . . . . . . . . . . . . . . . . . . . . . . . PM-1
