Operator Interface Products
PanelMate Operator Interface
Software
PanelMate Power Pro and
PanelMate PC Pro
Configuration Software
Application Description
Windows-based configuration
software is used to create PanelMate
Power Pro, PanelMate PC Pro and
PanelMate ePro configurations offline
on a PC. It also permits the editing of
character-based configurations from
earlier-version PanelMate Series
products. The following items can be
configured:
■ One-touch control (for touchscreen
models).
■ Customizable pixel-level graphics.
■ 8-state blink (for 256-level/color
models).
■ 3-level password protection.
■ International character set support.
■ Page change by operators and/or
PLC.
■ User-definable online system
prompts to permit non-English or
customized text that can be toggled
with standard online prompts by
operators.
■ Alarm window with a 100-alarm
capacity.
Features
■ Indicator templates.
■ Readout templates.
■ Bar templates.
■ Display templates.
■ Trend templates.
■ Table templates.
■ Variable-size control button
templates.
■ Pop-up maintenance window.
■ Alarm window.
■ Advanced trend templates.
■ Tag name file support.
■ Expression management.
■ 3000 symbol factory clipart.
PLC Communication Interfaces
Communication interfaces are avail-
able for the following programmable
controllers and are downloaded from
the configuration software.
Note: Multiple interfaces may be run
simultaneously on PanelMate Power Pro
1700, 2000, 3000, 4000 and 5000 units.
■ Allen-Bradley PLC-2, PLC-3, PLC-5
and SLC-500.
■ Cutler-Hammer D50, D300, D320.
■ GE ா Fanucா Series 5, 6, 90.
■ Mitsubishi ா “A” Series and “FX”
Series.
■ Modicon ா Modbusா ASCII/RTU.
■ Omron “C” Series plus CV500,
CV1000.
■ PLC-Direct DL 405 Family.
■ Square D ா SyMax.
■ Siemens ா S5 Series, 3964R Protocol,
AS511.
■ Simatic ா TI 305/405 and 500/505
Series.
■ Reliance AutoMate ா.
■ Toshiba T2.
High Speed Direct Connectivity Available
■ Allen-Bradley Data Highway and
Data Highway Plus.
■ Allen-Bradley Remote I/O Link.
■ GE Fanuc Genius ா I/O Network.
■ DeviceNet ீ.
■ Modicon Modbus Plus.
■ PROFIBUS ா.
Transfer Cables
PanelMate configuration software pack-
ages #PMPROSW and #PMPROSWSL
include a PanelMate 1100, 1700, 3000,
5000 (#0518) Transfer Serial Cable.
Product Selection
Table 32. Windows Configuration Software for PanelMate Power Pro and PanelMate PC Pro
Description Catalog
Number Price
U.S. $
PanelMate Power Pro Windows Configuration Software and
Manuals with Communication Software Interfaces for all major
PLCs and High Speed Industrial Networks on CD-ROM with Tag and
Expression Management and Symbol Factory Clipart.
#PMPROSW includes transfer serial cable for PM1700, 3000, 5000
(#0518). #PMPROSW includes electronic copies of manuals in .PDF
format. Single User License. PMPROSW 639.
Site License — See PMPROSW (for all users at 1 site location) PMPROSWSL 1,906.
PanelMate Power Pro Upgrade from previous PanelMate Power
Series Software to PanelMate Power Pro software version on CD-
ROM. Requires earlier version of PanelMate Power Series software
for installation. Single User License. PMPROSWUP 210.
PanelMate Power Pro Software Upgrade — Site License
Requires previous installation of PanelMate Power Pro Software
Site License (PMPROSWSL). On CD-ROM. PMPROSWSLUP 608.
Discount Symbol . . . . . . . . . . . . . . . . . . . . . . . . PM-1
