Description and controls – Eiki Visual System Presenter V-2500 User Manual
Page 7
1.
DESCRIPTION AND CONTROLS
1.
CAMERA HEAD
Rotate to shoot the printed materials and three-dimensional objects in shooting area and to shoot
the distance objects.
2.
REMOTE CONTROL STORAGE
Remote control unit works also when seating in the housing.
3.
S-VIDEO OUTPUT JACK
Used to connect TV monitor or VCR with S-VIDEO input jack.
4.
VIDEO OUTPUT JACK (2)
Used to connect TV monitor or VCR with video input jack.
NOTE : S-VIDEO AND VIDEO signal are output simultaneously and the unit can be connected to
TV monitor with S-VIDEO input jack and VIDEO input jack respectively.
5.
DC POWER INPUT JACK
Used to connect DC plug of AC adapter.
6.
CONVERSION LENS
Remove this lens to shoot the distance objects.
7.
IR RECEIVER
8.
MAIN BODY
9.
LEG STOPPER
10.
LEG
11.
SHOOTING AREA
