EVS200A/AW
49
5. SPECIFICATIONS
VIDEO STREAMING
Video Compression H.264/MPEG-4/M-JPEG
Video Resolution 4CIF, VGA, CIF, QVGA, QCIF
Video Quality 8 levels adjustable
Frame Rate Up to 30fps
Video Source
2 BNC composite, 1 V p-p / 75Ω
NTSC/PAL auto-sense
AUDIO
Compression Method IMA ADPCM (Pulse Code Modulation)
Operation Mode 2 way audio
NETWORK
Interface
10Base-T/100Base-TX auto-negotiation, RJ-45 socket
Support MDI/MDI-X auto crossover function
Supported Protocols
HTTP, TCP / IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS, DDNS,
NTP
Bandwidth Control Min. 64 kbps adjustable
Max. Client Limit 32 simultaneous clients
WIRELESS (EVS200AW)
Standard IEEE 802.11b/g
Antenna gain 2 dBi
ALARM
Alarm Input/Output 2/2
EVENT MANAGEMENT
Event Triggered
Alarm input, Manual trigger, Motion detection and Schedule
recording
Notification
Trigger alarm output, Send mail notification, Upload video to FTP,
Record video to SD card, Record video to PC and Network alarm
Pre- and Post- Alarm
Buffer
48MB RAM reserved for pre-alarm record up to 120 sec
LOCAL STORAGE
SD Card
Secure Disk physical layer specification version 2.0
Supports SDHC Host Specification
POWER
Power Supply 12 VDC
Power over Ethernet Yes (PoE 802.3af)
Power Consumption
EVS200A: 4.5W max. (12VDC)
EVS200AW: 6W max. (12VDC)
PHYSICAL
Weight 300g / 0.66lbs
Dimensions
77 (W) x 38 (H) x 117 (D) mm / 3” (W) x 1.5” (H) x 4.6” (D)
With Antenna:
77 (W) x 102 (H) x 153 (D) mm / 3” (W) x 4” (H) x 6” (D)
