EverFocus EVS200A/AW User Manual

Page 11

EVS200A/AW

○

Control Panel

: Zoom in

: Zoom out

: Focus far

Focus near

: Iris +

: Iris –

Arrow buttons: Click on an arrow button to

navigate in that direction.

: stop current action.

: User can select PTZ speed from High, Standard, Low

and Minimum.

Preset button: Click this button first, and input a preset position number

by clicking number key and then click “Go” button to move the camera to a preset
location.

Auto Pan button: Click this button first and input a preset auto pan No.

by clicking number key (1 for AB Pan, 2 for Endless Pan) and then click “Go” button
to run a preset auto pan.

Pattern button: Click this button first and input a preset pattern No. by

clicking number key (1 ~4) and then click “Go” button to run a preset Pattern.

Tour button: Click this button first and input a preset Tour No. by

clicking number key and then click “Go” button to run a preset tour.

Note: To use this function, user need to set Auto Pan in advance.

Note: 1. Click on live screen once to stop running pattern.

2. To use this function, user need to set Pattern in advance.

Note: To use this function, user need to set tour in advance.

Note: To use this function, user need to set preset location in advance.
