EVS200A/AW
32
4.7 EVENT
An event in the camera is when an Event Type is activated and causes certain actions
to be performed. The event type is the set of conditions that specifies how and when
which actions will be performed.
This table describes how to setup action types and event type.
Event
Action
Alarm
Input
1&2
Manual
Trigger
Motion
Detection
1&2 Video Loss
Schedule
Recording
Pre/Post
-Alarm Action Settings
Trigger
Alarm
output 1&2 x x x x
Contact Type: N.O./N.C.
Duration Time:
5sec~5min
Send Mail
notification x x x x
Attached I-frame.jpg or
attach Video file's.
Upload to
FTP x x x
x
(pre-alarm) x --
Record to
PC* x x x
x
(pre-alarm) x x --
Network
Alarm x x x x
Video File Format:
Re-trigger
Alarm x --
4.7.1 Event
The settings relating to event occurrences such as settings for the event
occurrence, motion, alarm and time mask can be configured on this page.
The "Event" page has 4 tabs: [Event] tab, the [Motion] tab, the [Alarm] tab and the
[Time Mask] tab.
Note: 1. * Record to PC only works when PC and IP camera are connected.
2. **Either Upload to FTP or Record to Network Storage can be selected to
record event video to remote site.
3. Up to 10 event types can be configured in the camera, and up to 3 of these
can be configured to upload images .
