Connecting 7.1-channel speakers
System for 7.1-channel surround playback.
o
Example connections when using surround back speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with surround back speakers.
.
FL
SW C
SL
FR
SR
SBR SBL
0
Set “Assign Mode” to “Surround Back” in the menu. ( v p. 187)
.
SW C SR SL FL FR SBR SBL
0
When using a single surround back speaker, connect it to the SURROUND BACK
L terminal.
