background image

Specifications are subject to change without notice.

sPeCIFICaTIONs

Video

Gain ............................................... Unity

Video input

Number/signal type ........................ 1 set of proprietary analog signals
Connectors .................................... 1 female RJ-45

Video output

Number/signal type ........................ 1 RGBHV, RGBS, component video (bi-level

and tri-level), S-video, composite video
(follows input type)

Connectors
MTP U R RSA SEQ ........................ 1 female 15-pin HD for RGB

3 BNC female for Y, R-Y, B-Y
(1) 4-pin mini DIN for S-video (Y/C)
1 BNC female for composite video

All other models ........................... 1 female 15-pin HD for RGB or Y, R-Y, B-Y

(1) 4-pin mini DIN for S-video (Y/C)
1 BNC female for composite video

Nominal level .................................. 1 Vp-p for Y of component video and

S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of
component video
0.3 Vp-p for C of S-video

Minimum/maximum levels.............. 0.8 V to 1.2 Vp-p
Impedance ..................................... 75 ohms (during video output only)
Return loss ..................................... <-30 dB @ 5 MHz (during video output only)
DC offset ........................................ <±20 mV with input at 0 offset

Sync

Output type .................................... RGBHV, RGBS
Standards ........................................ NTSC 3.58, NTSC 4.43, PAL, SECAM
Output level ................................... 4.0 V to 5.0 Vp-p, unterminated
Output impedance ......................... 87 ohms (24 mA)
Polarity ............................................ Positive or negative (selectable)

Audio – Mtp u R RSA SeQ, Mtp u R A

Gain ............................................... Unbalanced output: 0 dB;

balanced output: +6 dB

Frequency response ....................... 20 Hz to 20 kHz, ±1 dB (for DC coupling,

with jumpers 4 and 5 installed)

THD + Noise .................................. 0.15% @ 1 kHz, 0.3% @ 20 kHz at nominal

level

S/N ............................................... >70 dB at maximum output (unweighted)

Audio input – Mtp u R RSA SeQ, Mtp u R A

See MTP Series transmitters’ audio output specifications

Number/signal type ....................... 1 set of proprietary analog signals
Connectors ..................................... 1 female RJ-45
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu

Audio output – Mtp u R RSA SeQ, Mtp u R A

Number/signal type ....................... 2 mono, balanced/unbalanced
Connectors .................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance ..................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ...................................... ±1 dB channel to channel

contRol/ReMote – exteRnAl deVice

Pass-through, unidirectional or bidirectional
(MTP U R RSA SEQ, MTP U R RS SEQ or MTP U R RS)

Serial control port input/output ...... RS-232 via (1) 3.5 mm, 3 pole captive

screw connector

NOTE: The serial communications link of an MTP U R RSA SEQ,
MTP U R RS SEQ or MTP U R RS is unidirectional only, transmitter to receiver,
unless the receiver’s internal switch has been set.
Baud rates ...................................... Up to 38400 bps at up to 500' (152 m)

(Higher data rates and distances are
possible. Performance will vary based on
baud rate and cable length.)

Protocol .......................................... Data bits = 5 - 8

Stop bits = 1 or 2
Parity = odd, even, none
Flow control = XON, XOFF, none

NOTE: Protocol is mirrored between the transmitter and the receiver.

Serial control pin configurations ...... Captive screw connectors: 1 = TX, 2 = RX,

3 = GND

GeneRAl

External power supply ..................... 100 VAC to 240 VAC, 50/60 Hz, external,

universal; to 12 VDC, 2 A, regulated

Power input requirements ............... 12 VDC, 0.5 A
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) /

10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing

Cooling ........................................... Convection, unvented
Rack mount ..................................... Yes, with optional 1U rack shelf, part

#60-190-01 or 60-604-01; or VersaTools

®

rack shelf, part #60-190-20 or 60-604-20
Also furniture mountable with optional Mini
Under-Desk Mounting Kit, part #70-212-01;
or projector mountable with optional
projector mounting kit, part #70-217-01

Enclosure type ................................ Metal
Enclosure dimensions ..................... 1.7" H x 4.3" W x 3.0" D (1U high, quarter

rack wide)
4.3 cm H x 10.9 cm W x 7.6 cm D
(Depth excludes connectors.)

Product weight ............................... 0.6 lbs (0.3 kg)
Shipping weight ............................. 2 lbs (1 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit

Association)

Listings ............................................ UL, CUL
Compliances ................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF .............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTE: All nominal levels are at ±10%.

Model

Version Description

Part Number

MTP U R RSA SEQ A/V & RS-232 Universal Receiver w/SEQ ......... 60-869-01
MTP U R RS SEQ Video & RS-232 Universal Receiver w/SEQ ...... 60-869-02
MTP U R A

Video & Audio Universal Receiver ................... 60-869-03

MTP U R RS

Video + RS-232 Universal Receiver .................. 60-869-04
