ENVISION RESIDENTIAL INSTALLATION MANUAL
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
022-070
Superheat
022-070
Subcooling
Water Temp
Rise °F
Air Temp Drop
°F DB
1.5
133 - 148
205 - 225
17 - 26
10 - 14
18 - 22
18 - 22
3.0
129 - 144
185 - 205
20 - 29
7 - 11
8 - 10
18 - 22
1.5
139 - 154
280 - 300
8 - 11
8 -12
18 - 22
18 - 22
3.0
137 - 152
250 - 270
9 - 12
7 - 11
8 - 10
18 - 22
1.5
143 - 158
360 - 380
8 - 11
9 - 13
18 - 22
16 - 20
3.0
141 - 156
330 - 350
9 - 12
8 - 12
8 - 10
16 - 20
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
022-070
Superheat
022-040
Subcooling
048
Subcooling
060-070
Subcooling
Water Temp
Drop °F
Air Temp Rise
°F DB
1.5
73 - 79
279 - 304
7 - 13
2 - 6
11 - 15
4 - 8
7 -10
18 - 24
3.0
79 - 85
285 - 310
8 - 14
2 - 6
11 - 15
4 - 8
3 - 6
20 - 26
1.5
103 - 109
308 - 333
8 - 12
4 - 8
13 - 17
6 - 10
8 - 11
20 - 26
3.0
110 - 116
315 - 340
9 - 13
4 - 8
13 - 17
6 - 10
4 - 7
22 - 28
1.5
140 - 146
330 - 365
10 - 14
7 - 11
14 - 18
9 - 13
11 - 14
26 - 32
3.0
146 - 153
340 - 375
10 - 14
7 - 11
14 - 18
9 - 13
7 - 10
28 - 34
90
Entering Water
Temp °F
Heating -- No Desuperheater
30
Water Flow
GPM/Ton
Cooling -- No Desuperheater
50
70
50
70
Entering Water
Temp °F
Water Flow
GPM/Ton
Note: Cooling performance based on entering air temperatures of 80º F DB, 67º F WB.
Heating performance based on entering air temperature of 70º F DB.
Unit Operating Parameters
Single Speed Models
