ENVISION RESIDENTIAL INSTALLATION MANUAL
022 030 036 042 048 060 070
Compressor (1 each)
Factory Charge R410a, oz [kg] Vertical 62 [1.76] 62 [1.76] 82 [2.32] 82 [2.32] 98 [2.78] 110 [3.12] 146 [4.14]
Factory Charge R410a, oz [kg] Horizontal 60 [1.70] 66 [1.87] 82 [2.32] 82 [2.32] 98 [2.78] 94 [2.67] 122 [3.46]
Fan Motor & Blower
ECM
PSC
ECM 1/2 [373] 1/2 [373] 1/2 [373] 1/2 [373] 1/2 [373] 1 [746] 1 [746]
PSC 1/5 [149] 1/3 [249] 1/2 [373] 1/2 [373] 1/2 [373] 1 [746] 1 [746]
ECM
9 x 7
[229 x 178]
9 x 7
[229 x 178]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
PSC
9 x 7
[229 x 178]
9 x 7
[229 x 178]
10 x 10
[254 x 254]
10 x 10
[254 x 254]
10 x 10
[254 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
Coax and Water Piping
Water Connections Size - Swivel - in [mm] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4]
HWG Connection Size - Swivel - in [mm] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4]
Coax & Piping Water Volume - gal [l] 0.7 [2.6] 1.0 [3.8] 1.3 [4.9] 1.3 [4.9] 1.6 [6.1] 1.6 [6.1] 2.3 [8.7]
Vertical
Air Coil Dimensions (H x W), in. [mm]
28 x 20
[711 x 542]
28 x 20
[711 x 542]
28 x 25
[711 x 635]
32 x 25
[813 x 635]
32 x 25
[813 x 635]
36 x 25
[914 x 635]
36 x 25
[914 x 635]
Air Coil Total Face Area, ft2 [m2] 3.9 [0.362] 3.9 [0.362] 4.9 [0.451] 5.6 [0.570] 5.6 [0.570] 6.3 [0.641] 6.3 [0.641]
Air Coil Tube Size, in [mm] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5]
Air Coil Number of rows 3 3 3 3 3 4 4
Filter Standard - 2" [51mm] Pleated
MERV11 Throwaway, in [mm] 28 x 24
[712 x 610]
28 x 24
[712 x 610]
28 x 30
[712 x 762]
32 x 30
[813 x 762]
32 x 30
[813 x 762]
36 x 30
[914 x 762]
36 x 30
[914 x 762]
Weight - Operating, lb [kg] 305 [138] 320 [145] 365 [166] 380 [172] 420 [190] 455 [206] 480 [218]
Weight - Packaged, lb [kg] 315 [143] 330 [150] 375 [170] 390 [177] 430 [195] 465 [211] 490 [222]
Horizontal
Air Coil Dimensions (H x W), in. [mm]
18 x 30
[457 x 762]
18 x 30
[457 x 762]
20 x 35
[508 x 889]
20 x 40
[508 x 1016]
20 x 40
[508 x 1016]
20 x 45
[508 x 1143]
20 x 45
[508 x 1143]
Air Coil Total Face Area, ft2 [m2] 3.9 [0.362] 3.9 [0.362] 4.9 [0.451] 5.6 [0.570] 5.6 [0.570] 6.3 [0.641] 6.3 [0.641]
Air Coil Tube Size, in [mm] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5]
Air Coil Number of rows 3 3 3 3 3 3 3
Filter Standard - 2" [51mm] Pleated
MERV11 Throwaway, in [mm] 1 - 18 x 32
[457 x 813]
1 - 18 x 32
[457 x 813]
1 - 20 x 37
[686 x 940]
1 - 20 x 20
[508 x 508]
1 - 20 x 22
[508 x 559]
1 - 20 x 20
[508 x 508]
1 - 20 x 22
[508 x 559]
1 - 20 x 25
[508 x 635]
1 - 20 x 22
[508 x 559]
1 - 20 x 25
[508 x 635]
1 - 20 x 22
[508 x 559]
Weight - Operating, lb [kg] 307 [139] 322 [146] 370 [168] 385 [175] 425 [193] 460 [209] 485 [220]
Weight - Packaged, lb [kg] 322 [146] 337 [153] 385 [175] 400 [181] 440 [200] 475 [215] 500 [227]
4/9/07
Model
SINGLE SPEED
Copeland Scroll
Fan Motor Type/Speeds
ECM Variable Speed
PSC 3 Speeds
Fan Motor- hp [W]
Blower Wheel Size (Dia x W), in. [mm]
026 038 049 064 072
Compressor (1 each) Copeland 2-speed Scroll, UltraTech
Factory Charge R410a, oz [kg] Vertical 62 [1.76] 78 [2.21] 89 [2.52] 122 [3.46] 140 [3.97]
Factory Charge R410a, oz [kg] Horizontal 60 [1.70] 76 [2.16] 89 [2.52] 124 [3.52] 160 [4.54]
ECM Fan Motor & Blower
Fan Motor Type/Speeds ECM Variable Speed
Fan Motor- hp [W] 1/2 [373] 1/2 [373] 1/2 [373] 1 [746] 1 [746]
Blower Wheel Size (Dia x W), in. [mm]
9 x 7
[229 x 178]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
Coax and Water Piping
Water Connections Size - Swivel - in [mm] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4]
HWG Connection Size - Swivel - in [mm] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4] 1" [25.4]
Coax & Piping Water Volume - gal [l] 0.7 [2.6] 1.3 [4.9] 1.6 [6.1] 1.6 [6.1] 2.3 [8.7]
Vertical
Air Coil Dimensions (H x W), in. [mm]
28 x 20
[711 x 542]
28 x 25
[711 x 635]
32 x 25
[813 x 635]
36 x 25
[914 x 635]
36 x 25
[914 x 635]
Air Coil Total Face Area, ft2 [m2] 3.9 [0.362] 4.9 [0.451] 5.6 [0.570] 6.3 [0.641] 6.3 [0.641]
Air Coil Tube Size, in [mm] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5]
Air Coil Number of rows 3 3 3 4 4
Filter Standard - 2" [51mm] Pleated
MERV11 Throwaway, in [mm] 28 x 24
[712 x 610]
28 x 30
[712 x 762]
32 x 30
[813 x 762]
36 x 30
[914 x 762]
36 x 30
[914 x 762]
Weight - Operating, lb [kg] 305 [138] 370 [168] 420 [190] 465 [211] 480 [218]
Weight - Packaged, lb [kg] 315 [143] 380 [172] 430 [195] 475 [215] 490 [222]
Horizontal
Air Coil Dimensions (H x W), in. [mm]
18 x 30
[457 x 762]
20 x 35
[508 x 889]
20 x 40
[508 x 1016]
20 x 45
[508 x 1143]
20 x 45
[508 x 1143]
Air Coil Total Face Area, ft2 [m2] 3.9 [0.362] 4.9 [0.451] 5.6 [0.570] 6.3 [0.641] 6.3 [0.641]
Air Coil Tube Size, in [mm] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5] 3/8 [9.5]
Air Coil Number of rows 3 3 3 4 4
Filter Standard - 2" [51mm] Pleated
MERV11 Throwaway, in [mm] 1 - 18 x 32
[457 x 813]
1 - 20 x 37
[686 x 940]
1 - 20 x 20
[508 x 508]
1 - 20 x 22
[508 x 559]
1 - 20 x 25
[508 x 635]
1 - 20 x 22
[508 x 559]
1 - 20 x 25
[508 x 635]
1 - 20 x 22
[508 x 559]
Weight - Operating, lb [kg] 307 [139] 375 [170] 425 [193] 470 [213] 485 [220]
Weight - Packaged, lb [kg] 322 [146] 390 [177] 440 [200] 485 [220] 500 [227]
4/9/07
Model
DUAL CAPACITY
Physical Data (Single Speed)
Notes: Sizes 036, 042, 048 available with 1HP blower motor. (ICM only)
