E MULEX M ODEL 375 SAN S TORAGE S WITCH
U SER ’ S G UIDE C HAPTER 3: S WITCH M ANAGEMENT
E MULEX C ORPORATION 54
P ART N UMBER 00041369-002 R EV . B
Viewing Port Information
The Port Information page displays the Smart Settings, Serial ID (SID), and AL_PAs currently assigned
to each port. Initiator AL_PAs are highlighted in blue to differentiate them from target AL_PAs.
To view port information:
Click Port > Information.
The Port Information page appears.
Note: The Initiator AL_PA information can be used to easily identify attached devices when
configuring load balancing.
Field Description
Port Displays the current health of the port. See “Port Utilization and
Health” on page 52 for additional information on port health.
Smart Setting Displays the specific Smart Setting assigned to a particular port.
See
“Configuring the Port Smart Settings” on page 30 for more
information on the Smart Settings.
Serial ID (SID) When clicked, provides additional information about the SFP
inserted in the port, if an SFP is inserted in that particular port.
Identified ALPAs Displays all the AL_PAs attached to the port. Initiator AL_PAs
appear highlighted in blue.
Figure 3-28: Port Information page
