After receiving the switch, perform the following steps to ensure that the switch and other contents
arrived safely.
To unpack the switch:
1.
Inspect the outer shipping container for any damage that may have occurred in shipping. Report
any sign of damage to the appropriate shipping agency.
2.
Remove the switch and cables from the shipping container; save the shipping container, foam,
and antistatic bags—returning the switch in any other container is not advised.
Make sure the following parts are included:
•
Switch unit
•
RS-232 null-modem serial cable
•
Power cables (2)
•
Self-adhesive pads (4)
•
Retention clips (2), screws (4), and washers (4) for securing the power cords to the
switch.
•
Quick Install Card
•
Product Release Notes
•
Safety and Regulatory Guide
•
Additional documentation, including warranty information and the End User License
Agreement.
3.
Inspect the switch thoroughly. (If any signs of damage are seen, notify a sales representative
and/or the shipping agency.)
Installation Preparation ................................................ 7
Switch Installation ........................................................ 8
Switch LEDs .............................................................. 10
SFP Compatibility ...................................................... 13
Booting the Switch and SAN ...................................... 14
