45
OVERALL DIMENSIONS Width: 580 mm.
Depth: 500 mm.
CUT OUT DIMENSIONS Width: 550 mm.
Depth: 470 mm.
SUPPLY CONNECTIONS Gas:
R 1/2 inch (1/2 inch male) Rear right hand corner
Electric:
230-240V 50Hz supply, 3 core flexible cable with
non rewireable plug fitted with a 3 amp cartridge fuse.
IGNITION HT SPARK Spark Generator
Ispra Control's BF 80066 - 220-240V 0.6 VA T120
Spark Gap : Fixed
HEAT INPUT
Rear Left Burner
2.0 kW (6824 BTU/HR)
(semi rapid)
Front Left Burner
3.0 kW Natural Gas (10236 BTU/HR)
(rapid) 2.8 kW L.P.G. (9554 BTU/HR)
Rear Right Burner 2.0 kW (6824 BTU/HR)
(semi rapid)
Front Right Burner
1.0 kW (3412 BTU/HR)
(auxiliary)
APPLIANCE CLASS 3
APPLIANCE CATEGORY II2H3+
GAS SUPPLY Natural gas G20 / 20mbar
Instructions for the Installer
Engineer technical data
