Introduction
Installation and Site Specifications
Operator’s Guide Part No. 7B6090 1-6
VITROS ECi/ECiQ Immunodiagnostic System Version 2.0
Safety Requirements
The system meets all requirements for bearing the CE marking and safety
standards UL 3101-1, CSA C22.2 No. 1010.1, and IEC 1010-1.
Power Requirements
System
The system requires a dedicated, single phase, AC power line and one of
the following:
The system’s power cord should be plugged into a 3-wire, grounded
electrical outlet (receptacle type). The power cord should be 1.83 meters (6
ft.) in length and detachable.
• North America: IEC 320 to NEMA 5-20R
• Continental Europe: IEC 320 to CEE7 “Shuko”
UPS Dimensions:
I 49.4 cm (19.4 in.)
J 43.2 cm (17.0 in.)
K 8.9 cm (3.5 in.)
Printer Stand for Epson LQ/Model 570e and Epson LX/Model 300* Printer Dimensions:
L 73.2 cm (28.8 in.)
M 61 cm (24 in.)
N 87.1 cm (34.3 in.)
Printer Stand with Texas Instruments Omni 800/Model 830e Printer Dimensions:
L 73.2 cm (28.8 in.)
M 61 cm (24 in.)
N 91.4 cm (36 in.)
*Standard printer for the system. Printers are ordered in accordance with regional specifications.
Reference Dimension
Line Voltage Frequency
Maximum
Current Draw
Input Power
North America 120 volt AC 50–60 Hz 12 amps <1.5 KVA
Continental
Europe 200–240 volt AC 50–60 Hz 6 amps <1.5 KVA
