Introduction
Intended Use
Operator’s Guide Part No. 7B6090 1-4
VITROS ECi/ECiQ Immunodiagnostic System Version 2.0
Intended Use
For In Vitro Diagnostic use only. The VITROS
®
ECi/ECiQ
Immunodiagnostic System perform random access, batch, and STAT
immunodiagnostic assays on human fluid specimens. The system uses
chemiluminescence detection technology to provide accurate and reliable
results for heterogeneous assays. All reactions for a single quantitative,
semi-quantitative, and qualitative measurement take place within a coated
well.
Note: The availability of the ECi/ECiQ Immunodiagnostic Assays listed
and illustrated in this Guide are subject to regulatory registration,
licensing, clearance, or approval.
Installation and Site Specifications
Although equipment service representatives uncrate and install the
VITROS ECi/ECiQ Immunodiagnostic System at the laboratory site, the
site needs to be prepared according to specifications.
This section describes general requirements for installing the ECi/ECiQ
System at your laboratory, including physical and environmental
requirements.
Physical Dimensions
The following sections provide general component dimensions and a site
drawing that illustrates setup and space requirements.
Dimensions
Table 1-1 provides the physical dimensions of the system, the printer, and
the printer stand.
System
Printer:
Epson LX/
Model 300* Printer:
Epson LQ/
Model 570e
Printer:
Texas Instruments
Omni 800
Model 830e
Printer Stand
Width 111.8 cm (44 in.) 36.6 cm (14.4 in.) 41.1 cm (16.3 in.) 39.9 cm (15.7 in.) 61 cm (24 in.)
Depth 73.7 cm (29 in.) 27.5 cm (10.8 in.) 36.8 cm (14.4 in.) 34.5 cm (13.6 in.) 73.2 cm (28.8 in.)
Height 130.2 cm (51.25 in.),
top cover down
179.1 cm (70.5 in.),
top cover up
16.0 cm (6.3 in.) 16.0 cm (6.3 in.) 20.3 cm (8 in.) 71.1 cm (28 in.)
Weight 366 kg (807 lbs.) 4.4 kg (9.8 lbs.) 7.5 kg (16.5 lbs.) 7.3 kg (16 lbs.) 10.9 kg (24 lbs.)
*Standard printer for the system. Printers are ordered in accordance with regional specifications.
Table 1-1. Physical Dimensions
