9
Modelling lamps and fuses for 110 V & 230 V
Unit Modelling lamp 110V Modelling lamp 230V Socket Fuse
D-Lite RX ONE 100W / 23006 100W / 23002 E27 2.5AT
Programmable features - Reset English
Modelling lamp features & setup
How to „Reset“ the D-Lite RX ONE
In case you need to „RESET“ the D-Lite RX ONE to the manufacturer settings please follow the steps
below:
1. Switch the unit “off“
2. Press both flash power up / down buttons (10) at the same time and switch the unit on
3. The Digital LED multi display (6) flashes in fast mode
4. Do not continue to press the buttons, the resetting procedure is completed
Modelling lamp modes
* Do not use energy saving lamps
> Setting: Press “Modelling” button to set Modelling lamp ON to proportional mode, min.
mode, max. mode, or OFF
> LED Indication: • LED is on: only in proportional mode.
• LED is off: in min. / max. / off mode.
!
• Please use only original ELINCHROM modelling lamps with a maximum power
of 100W ( effective 150W).
Setup Visual-Flash-Control (VFC) mode
Proportional modelling lamp setup (PMS)
> Enter VFC setup :
1. Press “Prop” push button for more than 2 seconds, until the display shows “F.X” (“X” is 0 or 1) to
enter into the Modelling lamp setup menu.
2 . Use the “Flash-Power” up and down button to change setting:
- “F.0”: Visual-Flash-Control = OFF. Modelling lamp remains ON after flash.
- “F.1”: Visual-Flash-Control = ON. Modelling lamp switches off during recharging.
3. The display switches back to normal mode after approx. 4 seconds if no button is pressed. The
settings are automatically stored.
4. Standard setting is “F.0”, VFC = OFF
> Enter PMS setup:
1. Press “Prop” button for more than 2 seconds to enter into the Modelling lamp setup menu. The
display shows “F.X”, then press the “Prop” button once more to the PMS menu, the display shows
“-.X”
2. Use the “Flash-Power” up and down button to change the settings:
• “-.0”: PMS = OFF, Modelling lamp is set to maximum.
• “-.1”: PMS = -1 f-Stop, Modelling lamp is reduced by 1 f-stop.
(When using heads of different maximum power)
