18
• SLR Camera Sync speeds: SPEED mode up to
1/250 s, STANDARD mode 1/160 - 1/200 s.
• 5 selectable trigger modes, (4 Groups + All)
• 8 frequency channels.
• 40 Bit security encryption.
• Up to 60 m range indoors for standard mode and
up to 40 m in speed mode.
• Up to 120 m range outdoors for standard mode
and up to 60 m in speed mode.
• Battery life up to 6 Months - over 30’000 flashes.
• RX-feature buttons (Remote Control).
• Test trigger button and feature button.
• Integrated Hot-shoe (middle contact) improved.
• SYNC-socket for direct connection improved.
• Two flash modes, standard and speed.
• The “Standard” mode is fully compatible with
previous EL-Skyport versions.
• The SPEED function is available for Ranger
Quadra AS, BXRi 250 / 500 und D-Lite RX ONE
and all other units, when used with the Universal
Hot-shoe with
screw lock and
SYNC socket
Battery drawer
Battery (19372)
Minus pole on top
Flexible swivel
Antenna 360 ̊
Fig. 1
Battery Installation
1. Pull the battery drawer out carefully.
2. Place the Lithium battery, see Fig. 1 for correct polarity.
3. Close the battery drawer.
! CAUTION:
• Ensure correct polarity / minus pole on top.
• Use only the Lithium Battery CR2430 3.0 V 19372.
• Remove battery if the EL-Skyport Transmitter is not used for some time.
• Never short-circuit battery poles.
• Avoid direct sunlight or temperatures above 45°C. The battery may explode!
Hot-Shoe Connector with Screw-Lock
The new Hot-shoe connector with screw-lock and middle contact synchronisation is designed to fit digi-
tal and analogue cameras with maximum sync output of 3 V (the middle contact is the positive pole).
Operating Instructions
Speed.
• Status LED for EL-Skyport mode and battery
status.
• Improved housing, battery drawer and
switches.
• New Hot-shoe with screw-lock.
• New extra features; configure EL-Skyport with
the new EL-Skyport PC / MAC software 3.0.
You will appreciate the convenience of this
professional and powerful wireless device.
Note: Shutter speed and distance range are influenced
by interference from other 2.4 GHz electronic equipment
and reflections of ceilings, walls, floors, furniture, metall,
trees and humidiy in woods etc.
For better performance the Transmitter and Receiver
antenna should have direct sight, without any walls or
objects in - between.
EL-Skyport Transmitter SPEED //19350
Operating instructions :
2.4 GHz digital wireless Flash Trigger Transmitter
Features
EL-Skyport Transmitter Speed is designed with the latest 2.4 GHz Digital Wireless Technology.
