21
EL-Skyport Modules
EL-Skyport Universal SPEED (NEW) / Universal (previous version)
• Universal Receiver for all makes of Flash with a SYNC socket, conforming to Sync norms!
EL-Skyport Transceiver RX
• This Transceiver is only for Elinchrom RX units. The module operates all RX
features with the EL-Skyport software and triggers the flash.
EL-Skyport USB RX SPEED (NEW) / USB RX (previous version)
• To operate RX flash units via computer the USB module should be used in
conjunction with the EL-Skyport Transceiver RX and the EL-Skyport software.
Troubleshooting
Should an error occur, first check the following points:
Having this problem? Check the following points:
No flash unit can be triggered
with the Transmitter
Mode “All” is selected  Check if the Transmitter is switched ON.
 Check battery polarity.
 Check if the Receiver module is connected correctly to the unit.
 Check if the frequency selector switch is set to the same channel.
 Check if Transmitter is in the same trigger mode Speed or Standard.
Some units do not fire when
triggered with the Transmitter
Mode “Grp” is selected  Check if the Channel selector switch is set to the same Group.
 Reduce distance to any “not working” unit.
 Check if Transmitter is in the same trigger mode Speed / Standard.
TEST flash works, but the camera
will not trigger flash unit  Check hot-shoe fitting.
 Connect the 2.5 mm to PC SYNC cable instead of hot-shoe connection.
Limited Distance range  Reposition the units.
 Increase the distance to walls and ceilings.
 Position the antenna of Transmitter and Receiver.
 Use an RX extension cable to reduce the distance between the modules.
English
Universal Speed
& Universal
Transceiver RX
19353
USB RX Speed
& USB RX
