18
Specifications
Transmitting section
Oscillator type Crystal-controlled PLL synthesizer
RF power output
1 mW/10 mW/50 mW (e.r.p) selectable
Occupied RF bandwidth
192 kHz or less
Audio delay MODE1: 1.5 ms
MODE2: 1.0 ms
MODE3: 2.1 ms
Allowable deviation of transmission frequency
±6.5 ppm
Type of emission
G1E or G1D
Modulation method
π
/4 Shift QPSK
Audio section
Maximum input level
MIC: –22 dBu (with 0 dB attenuator)
LINE: +24 dBu
Audio attenuator adjustment range (pad)
0 dB to 48 dB (3-dB steps, MIC input
mode only)
Microphone input connector
XLR-3-11C (female)
Input impedance
4.7 kohms or more
Frequency response
20 Hz to 22 kHz
T.H.D MODE1, MODE2: 0.03% or less
MODE3: 0.3% or less
0 dBu = 0.775 V
General
Operating voltage
3 V DC, with two LR6 (AA) alkaline
batteries
Battery life Continuous operating time
5 hours (at 25 °C (77 °F), 10-mW output
using Sony LR6 (AA)-size alkaline
batteries with CODEC MODE set to
MODE1 and the wireless remote
control function off and DIMMER
MODE set to AUTO OFF and +48V
set to OFF)
Operating temperature
0 °C to 50 °C (32 °F to 122 °F)
Storage temperature
–20 °C to +60 °C (–4 °F to +140 °F)
Wireless remote control
2.4-GHz IEEE802.15.4 compliant
Dimensions (unit: mm (inches))
Mass Approx. 245 g (8.6 oz) including batteries
Supplied accessories
Spare battery case (1)
Soft case (1)
USB adapter cable (1)
Before Using this Unit (3)
CD-ROM (1)
Optional accessories
Electret Condenser Microphones
ECM-673/9X
ECM-674/9X
ECM-678/9X
Design and specifications are subject to change without
notice.
Notes
• Always verify that the unit is operating properly before use.
SONY WILL NOT BE LIABLE FOR DAMAGES OF ANY
KIND INCLUDING, BUT NOT LIMITED TO,
COMPENSATION OR REIMBURSEMENT ON ACCOUNT
OF THE LOSS OF PRESENT OR PROSPECTIVE PROFITS
DUE TO FAILURE OF THIS UNIT, EITHER DURING THE
WARRANTY PERIOD OR AFTER EXPIRATION OF THE
WARRANTY, OR FOR ANY OTHER REASON
WHATSOEVER.
• SONY WILL NOT BE LIABLE FOR CLAIMS OF ANY
KIND MADE BY USERS OF THIS UNIT OR MADE BY
THIRD PARTIES.
• SONY WILL NOT BE LIABLE FOR THE TERMINATION
OR DISCONTINUATION OF ANY SERVICES RELATED
TO THIS UNIT THAT MAY RESULT DUE TO
CIRCUMSTANCES OF ANY KIND.
