13
To reset the accumulated time indication
1
Hold down the SET button until the time indication
flashes.
2
Press the – button so “00:00 RESET” appears, and
then press the SET button.
Using wireless remote control, this function can be
controlled from the receiver and other devices.
For details on wireless remote control function, see
“Using the Cross Remote” on page 7.
+48 V power supply setting (+48V)
You can turn the +48 V power supply on or off for
microphones that require an external power supply.
OFF: Power is not supplied to the connected microphone.
ON: Power is supplied to the connected microphone.
Using wireless remote control, this function can be
controlled from the receiver and other devices.
For details on wireless remote control function, see
“Using the Cross Remote” on page 7.
The +48 V power supply can be turned on or off,
regardless of INPUT LEVEL setting. Note, however, that
the +48 V power is actually supplied only when INPUT
LEVEL is set to MIC.
Setting the encrypted transmission
function
(ENCRYPTION)
You can set the encrypted transmission function.
SECURE KEY: Sets the secure key method.
PASSWORD: Sets the password method.
OFF: The encrypted transmission function is not used.
For details, see “Using the Encrypted Transmission
Function” on page 8.
Setting the audio codec mode
(CODEC MODE)
MODE1: This audio codec mode is compatible with the
first generation DWX series.
MODE2: Delay times are reduced in this audio codec
mode. Audio quality is also improved when compared to
MODE1. We recommend using this mode under normal
circumstances.
MODE3: This audio codec mode prioritizes stable
transmission performance. Additional signal processing is
used to suppress noise and audio interruptions caused by
unexpected interference, resulting in more reliable
transmission.
The audio delay durations that occur when transmitting
and receiving with each mode will differ depending on the
receiver’s operating environment.
For details, refer to the operating instructions supplied
with the receiver.
The audio codec mode setting can be configured via the
wireless remote control function from the receiver, for
example.
For details, see “Using the Cross Remote” on page 7.
Setting the maximum RF output
power
(MAX RF POWER)
You can set the maximum RF output power of the unit.
1mW MAX: Sets the maximum to 1 mW.
10mW MAX: Sets the maximum to 10 mW.
50mW MAX: Sets the maximum to 50 mW.
• The setting for this function cannot be changed during
actual signal transmission. To change the setting, turn
off the transmitter first. Then, while holding down the
SET button, turn the power on. And then, change the
setting after the signal transmission has stopped.
• To start signal transmission with the selected RF output
power setting, turn off the power and then turn it on
again.
• Always perform pairing after changing the maximum
RF output power setting for a transmitter. If you fail to
do so, configuration of RF output power settings via the
wireless remote control function may become
impossible.
For details on pairing, see “Using the Cross Remote” on
page 7.
Generating an internal signal
(INTERNAL SG)
This transmitter generates a 1-kHz reference level sine
wave that can be used to adjust or check the audio level of
the receiver or the system that you are using. This internal
signal is outside the control of the attenuator.
1 kHz: A 1-kHz internal signal is generated.
OFF: An internal signal is not generated.
If the transmitter is turned off while the reference signal
function is on, the function will turn off automatically.
Using wireless remote control, this function can be
controlled from the receiver and other devices.
Note
Notes
Note
