©2015 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features, design, and specifications are subject to change without notice.
The values for mass and dimension are approximate.
“SONY”, “Exmor”, “XDNR”, and “View-DR” are trademarks of Sony Corporation.
Peripheral Equipment
Distributed by
MK20016V1OHB15MAY
12x Effective Power Zoom
The SRG-120DU provides up to 12x optical zoom and 12x digital
zoom, which results in tremendous 144x High Power Zoom in total.
It’s very beneficial when close-up images are required.
VISCA-over-IP
The SRG-120DU can be controlled via the VISCA™ protocol over IP
connections, as well as a RS-232. It is compatible with Sony’s
RM-IP10 IP Remote Controller to enable comfortable pan, tilt, and
zoom operation with an optical three-axis joystick.
Other Features
• Wide Field of View
The SRG-120DU provides a wide horizontal viewing angle of 71
degrees. It’s ideal for the usage at small- and mid-sized rooms.
• High Sensitivity
The SRG-120DU provides superb sensitivity of minimum illumination
1.8 lx, which enables capturing images in low light environments.
• Compact and Stylish Body
Its all-in-one compact and lightweight design makes this camera
easy to install in a variety of locations.
• Quick and Silent Pan, Tilt, and Zoom
The SRG-120DU features quick and silent pan, tilt, and zoom
capabilities. It’s ideal for use in noise-restricted environments such
as classrooms and meeting rooms.
RM-IP10
IP Remote Controller
• Comfortable P/T/Z operation with the optical three-axis joystick
• Versatile camera adjustment by simple panel operation
• The use of IP technology allows flexible installation and easy operation
12x Optical
Zoom
Wide-end Tele-end
* Simulated images
Specifications System Configurations
Software-based Videoconferencing Systems and UCC Systems
Multimedia Streaming Systems
SRG-120DU
SRG-120DU
PC
PC
or
Infrared Remote Commander
(supplied)
RM-IP10
IP Remote Controller
Video Signal
Remote Control (VISCA or LAN) Signal
Signal Flow
,
* Presets x 16 when controlled via VISCA. Presets x 6 when using the supplied IR remote commander.
SRG-120DU
Camera
Image Sensor 1/2.8 Exmor CMOS
Image Sensor (Number of Effective Pixels) Approx. 2.1 Megapixels
Signal System 1080/59.94p,50p,29.97p,25p
720/59.94p,50p,29.97p,25p
Minimum Illumination (50IRE) 1.8 lx (50IRE, F1.8, 30 fps)
S/N Ratio 50 dB
Gain Auto/Manual (0 to +43 dB)
Shutter Speed 1/1 to 1/10000 sec (59.94 Hz system)
1/1 to 1/10000 sec (50 Hz system)
Exposure Control Auto, Manual, Priority AE (Shutter,Iris),
Exposure compensation, Bright
White Balance Auto, Indoor, Outdoor, One-push auto, ATW, Manual
Optical Zoom 12x
Digital Zoom 12x
Focusing System Auto/Manual
Horizontal Viewing Angle 71 degree (Wide)
Focal Length f=3.9 mm (Wide) to 46.8 mm (Tele)
F1.8 to 2.0
Minimum Object Distance 10 mm (Wide) ~ 1500 mm (Tele)
Pan/Tilt Angle Pan: ±100° Tilt: ±25°
Pan/Tilt Speed (Max.) Pan: 300°/sec Tilt: 126°/sec
Preset Position 16*
Camera Features
Auto ICR No
Wide-D Yes
Image Stabilizer No
Image Flip No
Auto Power Off No
Night Power Off No
Interface
HD Video Output USB 3.0
SD Video Output –
Camera Control Interface RS-232/RJ-45
Sync. System INT
General
Power Requirements DC 12 V (DC 10.8 to 13.2 V)
Power Consumption 16.8 W
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to +60°C (-4°F to +140°F)
Dimensions (W x H x D) 153 Ч 156 Ч 153 mm (6 1/8 x 6 1/4 x 6 1/8 inches)
Mass 1.45 kg (3 lb 3.1 oz)
Body Color Silver
Wide Conversion Lens Attachable No
Mountable Angle ±15°
Ceiling Mount No
Supplied Accessories AC power adaptor (1), AC power cable (1),
IR remote commander unit (1)
