The LMD-B170 monitor can control the aperture level of a video signal, and display images on the screen
with sharpened edges to help camera focus operation. Further to this, the sharpened edges can be
displayed in user-selectable colours (white, red, green, blue, and yellow) for more precise focusing.

Time code function

LTC and VITC time code can be displayed at the top or bottom of the picture.

Side by side function

The side by side function of the LMD-B170 allows simultaneous display of two input signals on the monitor’s
screen. This function helps with colour adjustment and setting of camera frames. This function works when
synchronous SDI signals are input.

On-screen tally

The monitor is also equipped with a three-colours red, green and yellow on-screen tally function. The position
of the tally display can be changed to either the upper or lower section of the screen.

Flip functions

The Flip function turns the reversed image to a normal view, horizontally or vertically.

DC low power indicator

DC power supply is available in the range of 12V to 17V. The power indicator blinks when the DC power
supply is low.

Wall-mount capability

There are also wall-mount 100mm pitch holes on each monitor’s rear panel. A built-in AC circuit allows you
to install the monitor more easily and flexibly than a monitor with an AC adaptor.

Natural ventilation system

There is no cooling fan inside and making the monitor suitable for video shooting and critical audio
operations.

LMD-B170

4
