5
Getting Ready
Main Screen
This is the main screen of the P-20HD.
Using the Menus
This explains how to display menus and make settings for video and
for the P-20HD itself.
* The menu is also shown on the display that is connected to the
OUTPUT PREVIEW connector.
1. Press the [MENU] button to display the menu.
The [MENU] button lights up, the menu categories are displayed.
2. Turn the [VALUE] knob to select a category, and
press the [VALUE] knob to confirm.
The menu for the selected category is displayed.
3. Turn the [VALUE] knob to select a menu item, then
press the [VALUE] knob to confirm.
The cursor moves to the setting value.
5 If the menu item is located at a deeper level, repeat step 3.
5 Pressing the [EXIT] button moves you back one level higher.
4. Turn the [VALUE] knob to change the value of the
setting.
5 By turning the [VALUE] knob while pressing it, you can change the
value more greatly.
5 Pressing and holding the [VALUE] knob returns the current menu
item you’re setting to its default value.
5. Press the [VALUE] knob to apply the setting.
The cursor returns to the menu item.
6. Press the [MENU] button to quit the menu.
LIVE IN screen REPLAY screen
Playback time counter
(HH : MM : SS ; FF)
Video recording counter
(HH : MM : SS ; FF)
Available
recording
time
Red border shown on the video that’s being output
Audio level meter of the
replay video
Audio level meter of the
input video
Playback speed of replay video
