6
Desk Top RSH-SERIES
8. Carefully pull up the laminate from the lower roll up
towards the first idle bar and then around the back
side of the second Idler (Caution: lower roller may
be hot).(Picture 3)
9. Tack the lower film to the upper film that is resting
on the main hot rollers (Picture 4).
10. Reinstall the Front Table and close the Safety
Cover.
11. Adjust the nip setting to 1/4'' (6mm).
12. Insert and push the leader board into the hot
rollers (Picture 5).
13. Adjust the nip setting to "Laminating" mode.
14. Push the Run button.
15. Press the Run button and adjust the supply roll
tension knobs by rotating clockwise or
counterclockwise. Turn it until the supply roll
films have some resistance (the tension
varies depending on the film thickness; the
thicker the film the more tension is required)
(Picture 6).
16. Press Stop button when the leader board has
completely exited the rear of the unit.
17. Use the Cross Cutter to cut the leader board from
the web (see page 18).
18. Peel Trim any excess film off of the leader board
edges. The leader board can be reused.
19. Set the roller nip setting to the appropriate position
for the lamination or encapsulation application.
Picture 3
Picture 4
Picture 5
Picture 6
