5
6. THREADING FILM
6.1. HOT FILM DOUBLE SIDED LAMINATING
UPPER ROLL FILM
ADHESIVE SIDE
IDLE BAR
LAMINATING H O T ROLLERS
GLOSSY SIDE
PULL ROLLERS
ADHESIVE SIDE
LOWER ROLL FILM
IDLE BAR
GLOSSY SIDE
1. Turn the power switch on ("I" position). Power switch is located
in the rear of the unit on the left side.
2. Turn on the lower hot roller by pressing S/D
button on the control panel. This button will be lit
when the lower heat is on.
3. Complete the "Loading Film" steps as shown on
page 4.
4. Set the temperature and speed according to the
Recommended Temperature and Speed section.
5. Remove the Front Table.
6. Pull down the upper film over the Safety Cover to
the lower film; align and center the lower film to
upper film (Picture 1).
7. Rewind the upper film until the film aligns with the
Safety Cover.
8. Thread the film under the Upper Idle Bar and
underneath the Safety Cover until the film rests on
the upper roller (Picture 2).
Picture 1
Picture 2
