M1: File Offset Description
270 Number of blocks transferred from processor to module
271 Number of blocks parsed by module
272 Number of block errors in module
Port 1 Status
M1: File Offset Description
273 Port 1 receive state:
–1 = Listening for data
1 = Receiving Port Data
2 = Waiting for Backplane transfer
274 Port 1 receive character count
275 Port 1 receive block count
276 Port 1 transmit state:
0 = Waiting for Data to Send
1 = RTS On
2 = RTS Timeout
3 = Sending data
4 = Waiting for RTS Off
5 = RTS turned off
30 = Intercharacter Delay
31 = Intercharacter Delay
32 = Intercharacter Delay
100 = Message Delay before Transmit
101 = Message Delay before Transmit
277 Port 1 transmit character count
278 Port 1 transmit block count
279 Port 1 error word
Port 2 Status
M1: File Offset Description
280 Port 2 receive state:
–1 = Listening for data
1 = Receiving Port Data
2 = Waiting for Backplane transfer
281 Port 2 receive character count
282 Port 2 receive block count
