- 14 -


Bank No. Port No.




Bank Status Port Status

7-Segment LED Indication

:

You can press the button in order like mentioned-above dia-
gram.
When you select one of the PC ports and this PC is shut down
or this PC port is disconnected to the PC, the selected port
LED will flash. When you select one of the PCs ports and this
PC is powered on, the selected port LED is lit.

Reset Button (Bank Select and Port Select ):
To press both “Bank Select” button and “Port Select” button of
master bank simultaneously can reset KVM switch. This reset
action will not only return KVM switch back to initial state, but
also re-check all of slave banks which connected to master
KVM Switch.
If you add a new KVM Switch as a slave bank, please use
reset button of master KVM Switch to automatic assign a new
ID to it. You can view this new slave bank go through OSD
menu. The KVM Switch as a slave bank does not be reset by
reset command.

3.3 Selecting PC through Hot Key

You can also conveniently command KVM switch by switching
ports through simple key sequences. To send commands to
KVM switch, the “SCROLL LOCK” key must be pressed
twice within 2 seconds.
You will hear a beep for confirmation
and the keyboard is in hot key mode. If you have not

pressed

any key in hot key mode within 2 seconds (It means to
key in any key follows up “Scroll Lock” “Scroll Lock” key ),

3

0

8
