MTP 4T 15HD RS • Reference Information
Reference Information, cont’d
MTP 4T 15HD RS • Reference Information A-4 A-5
Listings............................................ UL, CUL
Compliances ................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................... 30,000 hours
Warranty ........................................ 3 years parts and labor
N All nominal levels are at ±10%.
N Specifications are subject to change without notice.
Part Numbers
MTP transmitter and receivers
N A complete transmission system requires one of the four
transmitters built into the MTP 4T 15HD RS and at
least one MTP receiver.
Transmitter assembly Part number
MTP 4T 15HD RS transmitter assembly 60-905-01
Compatible receivers Part number
MTP RL 15HD RS receiver 60-735-01
MTP RL 15HD RS SEQ receiver 60-735-02
Included parts
The following parts are included in each order for an
MTP 4T 15HD RS:
Included parts Part number
Rubber feet (self-adhesive) (4)
MBD 149 1U Through-desk and rack
mounting kit
70-077-03
IEC power cord 27-044-01
Tweeker (small screwdriver)
User’s Manual
Cables
N Enhanced Skew-Free™ A/V UTP cables are not
recommended for Ethernet/LAN applications.
Enhanced Skew-Free™ A/V cable Part number
Enhanced Skew-Free A/V cable
(cut, various lengths)
26-569-xx
Enhanced Skew-Free A/V 1000’
(Bulk) (non-plenum)
22-141-03
Plenum enhanced Skew-Free A/V 1000’
(Bulk)
22-142-03
Connectors
Enhanced Skew-Free™ A/V cable Part number
CAT 6 jack (black) 10-463-10
CAT 6 jack (red) 10-463-11
CAT 6 jack (blue) 10-463-12
CAT 6 jack (orange) 10-463-13
CAT 6 jack (gray) 10-463-14
CAT 6 jack (white) 10-463-15
CAT 6 jack (ivory) 10-463-16
