EN
6
1 / INSTALLING YOUR APPLIANCE
4 cm
4 cm
4 cm
Entrée d'air
Sortie d'air
4 cm
A
vide sanitaire
51 60
49
56
6,4
Above a cabinet
with a door or drawer
• CHOOSING THE POSITION
The distance between the edge of your
appliance and the side and rear walls (or parti-
tions) must be at least four centimetres (zone A).
Your appliance can be built in above a cabinet,
oven or built-in electrical appliance without any
restriction. Simply check that the air intakes and
air outlets are free of obstruction (see chapter:
“description of your appliance”).
BUILDING-IN
Follow the diagram above.
Glue the foam seal underneath your appliance,
following the perimeter of the hole in the work-
top, upon which your appliance will rest. This will
ensure a good seal against the worktop.
Attach the clips to the hob
(depending on the
model ).
• Above an oven
MIN 4 mm
Note
If your hob is located above your oven, the hob’s thermal safety devices can impede the
simultaneous use of the hob and the oven’s pyrolysis programme.
Your hob is equipped with an anti-overheating safety system.
This safety device can trigger, for example, when the hob is installed over an oven that is not suf-
ficiently insulated. If this occurs, a series of small lines appears on the control panel. In such cir-
cumstances, we recommend that you increase the hob’s ventilation by creating an opening in the
side of the cabinet, (8 x 5 cm), and/or installing an oven insulation kit available from the after-sales
department (Ref.75X1652).
You can also install your hob above a dishwasher. In this case, your work surface must measure
at least 900 mm in height to allow correct ventilation of your cooking hob and you can also install
the dishwasher insulation kit available from the after-sales department (ref.: 77X7781).
