OPERATING
INSTRUCTIONS
COUPLING PROCEDURES
1. Make sure coupling area is
flat, level and clear of persons
and obstacles.
2. Center fifth wheel with kingpin and back up straight.
3. Back tractor close to trailer and STOP.
4. Chock trailer wheels.
5. Connect brake lines
and light cord.
6. Support slack in lines
to prevent interference.
7. Set trailer brakes.
OK
TRAILER
(TOP)
KINGPIN
XL-FW418-01 Rev C
