EXAMPLE: &%Z61 ,1 APO is not active.
COMMAND 61: AUTOMATlC PRINT ORIENTATION (APO) (LASER)
Laser printers automatically control page orientation if the user decides to
activate auto print orientation (APO). Refer to the page orientation logic chart
in the computer output reduction section of the manual.
VALUE DESCRlPTlON
* 0 Auto Print Orientation (APO) is ACTIVE. The page
dimensions of a document are checked to determine if the
data should be printed in landscape because the width is
greater than the length.
1 Auto Print Orientation (APO) is NOT ACTIVE. Print orientation
is controlled by the orientation selections specified in
Commands 62, 63, and 64.
NOTE: APO active is the recommended selection.
A user can manipulate the page dimensions using SCS commands to
control the orientation of the printing as long as the page size required
is 8 1/2" X 11” or smaller.
COMMAND 62: PRIMARY PAPER TRAY ORIENTATION (LASER)
The SCS (LU1) PPM command, which specifies the source for the paper,
assigns a printing orientation to the primary paper tray. Refer to the page
orientation logic chart in the computer output reduction section of the manual.
This command duplicates the IBM 3812 and 4028 printer’s feature with the
additional selection of option 3 below.
VALUE DESCRlPTlON
*0 Computer Output Reduction (COR) Mode is active when
paper is specified to be selected from the primary tray.
1 PORTRAIT orientation will occur using the active font when
the primary tray is specified.
2 LANDSCAPE orientation printing occurs using the active font
when the primary tray is specified.
A-23
