DF-710, MT-710, BF-710, PH-5A, PH-5B AND PH-5C OPERATION GUIDE 25
Tray C
If the illustration shown displays on the machine’s
operation panel, there is a paper jam in the
conveyor section to Tray C.
1 While pushing the finisher release lever, pull the
finisher out from the machine.
2 Open the top cover and remove the jammed
paper.
3 Close the top cover and re-install the finisher back into position on the machine.
Conveyor / Internal Tray
If the illustration shown displays on the machine’s
operation panel, there is a paper jam in the
conveyor section to the internal tray.
NOTE: If frequent jamming occurs in the
conveyor or internal tray, the paper may be
excessively curled. Adjust curling referring to
page 31 for when output pages are curled.
1 Open the tray C and front cover.
